UFC721AE101 3BHB002916R0101 Differential Analog Input Module-KIMI
- Part number：UFC721AE101 3BHB002916R0101
- Product Origin：Sweden
- HS CODE：8537109021
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
ABB UFC721AE101 3BHB002916R0101 8-Channel Differential Analog Input Module (ADCVI)
UFC700 Series - High-Precision Signal Conversion & Isolation for AC 800M/DCS 800xA
1. Product Overview
The ABB UFC721AE101 (Ordering Code: 3BHB002916R0101) is an 8-channel differential analog input module (ADCVI) belonging to the UFC700 series, seamlessly integrated with ABB AC 800M controllers and DCS 800xA distributed control systems. As a core component for industrial analog signal acquisition, it achieves high-precision conversion and isolation of standard industrial current (4-20mA/0-20mA) and voltage (0-10V/1-5V) signals, with 16-bit resolution and ±0.1% FS accuracy, and 1500V AC isolation performance to eliminate ground loop interference and electrical noise in harsh industrial environments. Equipped with redundant 24V DC power input and comprehensive fault protection functions, it is an ideal choice for critical process control scenarios in power generation, oil & gas, petrochemical, chemical and other industries that require high-precision and uninterrupted signal acquisition.
Key Specifications
• Model: UFC721AE101 | Ordering Code: 3BHB002916R0101 | Brand: ABB | Series: UFC700
• Compatibility: ABB AC 800M Controller, DCS 800xA Distributed Control System
• Type: 8-Channel Differential Analog Input Module (ADCVI)
• Input Signals: 4-20mA/0-20mA DC Current; 0-10V/1-5V DC Voltage (Configurable per Channel)
• Resolution: 16-bit | Accuracy: ±0.1% Full Scale (FS)
• Update Rate: 10ms per Channel | Sampling Frequency: 100Hz
• Isolation: 1500V AC (1min, Signal-to-Control Side)
• Common Mode Rejection Ratio (CMRR): >80dB @ 50/60Hz | ESD Protection: ±8kV (Contact), ±15kV (Air)
• Power Supply: 24V DC (18-32V DC), Redundant Dual Input | Power Consumption: 6W (Typical)
• Operating Temperature: -20°C to +60°C | Storage Temperature: -40°C to +85°C
• Relative Humidity: 5%–95% (Non-Condensing) | Protection Class: IP20 (Front Panel)
• MTBF: >150,000 Hours | Dimensions: 130mm(W) × 100mm(D) × 42mm(H)
• Mounting: 35mm DIN Rail | Net Weight: 0.5 kg | Gross Weight: 0.81 kg
• Protection Features: Overcurrent, Undervoltage, Overtemperature, Short-Circuit Protection
2. Core Features
• 8 Differential Channels: Independent per-channel configuration for current/voltage signals
• High-Precision Conversion: 16-bit resolution and ±0.1% FS accuracy for reliable data acquisition
• 1500V AC Isolation: Eliminates ground loops and electrical noise interference
• Redundant Power Input: 24V DC dual input ensures uninterrupted operation in critical applications
• Fast Update Rate: 10ms per channel for real-time reflection of field process parameter changes
• Comprehensive Protection: Overcurrent, undervoltage, overtemperature, and short-circuit protection
• LED Diagnostics: Power, Run, Fault, and Channel Activity indicators for quick status checks
• DIN Rail Mounting: Tool-less installation on 35mm standard DIN rail for easy deployment and maintenance
• Seamless Integration: Plug-and-play with AC 800M/DCS 800xA without additional drivers
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Power Generation: Boiler temperature/pressure acquisition, turbine vibration signal collection, hydropower plant water level/flow monitoring
• Oil & Gas: Pipeline pressure/flow sensing, compressor operating parameter acquisition, offshore platform process control
• Petrochemical & Chemical: Reactor temperature/pressure/level monitoring, distillation unit flow signal acquisition
• Water & Wastewater Treatment: Pump pressure/flow sensing, sewage treatment pool level monitoring
• Metallurgy & Manufacturing: Furnace temperature acquisition, production line speed/load monitoring
• Renewable Energy: Wind turbine hydraulic system pressure monitoring, solar inverter DC voltage/current acquisition
4. Installation & Maintenance
Installation: Mount on 35mm DIN rail; Connect redundant 24V DC power; Wire field sensor signals to differential input terminals; Connect to AC 800M/DCS 800xA backplane bus; Configure via ABB Control Builder; Test signal acquisition accuracy.
Maintenance: Daily - Check LED status (Power/RUN green normally, Fault red off); Weekly - Inspect terminal tightness and clean dust; Monthly - Verify analog input consistency with field sensors; Annual - Full-channel calibration, check isolation performance, update firmware.
Safety Notes: De-energize before wiring; Use ESD protection during handling; Follow ABB wiring specifications for shielding and grounding (single-point grounding recommended).Technical Document | UFC721AE101 3BHB002916R0101 | ABB 8-Channel Analog Input Module (ADCVI)
