DSSR122 48990001-NK Double Busbar Protection Relay-KIMI

Part number：DSSR122 48990001-NK
Product Origin：Sweden
HS CODE：8537109021
Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ABB DSSR122 48990001-NK | Double Busbar Protection Relay

Numerical protection relay for medium-voltage double busbar systems - fault detection, selective tripping, and SCADA integration for power distribution networks

1. Product Overview

The ABB DSSR122 48990001-NK is a dedicated numerical double busbar protection relay engineered for medium-voltage (MV) power distribution systems, providing fast, selective fault detection and isolation for double busbar configurations with bus couplers and circuit breakers. It integrates multiple protection functions including busbar differential protection, breaker failure protection, and intertrip logic, with a high-speed sampling rate of 1 kHz for real-time fault analysis and tripping within milliseconds. The relay supports flexible configuration via local HMI or PC-based **Control Builder** software, features extensive communication interfaces (Modbus RTU, IEC 61850 GOOSE/MMS for SCADA integration), and offers comprehensive event logging (up to 1000 events) for post-fault analysis. With an operating temperature range of -25°C to +70°C, IP54 front-panel protection, and compliance with IEC 61850, IEC 60255, and IEEE C37.90 standards, it is ideal for power substations, industrial plants, and renewable energy facilities requiring reliable busbar protection and grid stability.
