GE Fanuc IC755CSS12CDB-BG QuickPanel+ 12.1" Integrated HMI Operator Interface

Product Description

The GE Fanuc IC755CSS12CDB-BG (now Emerson QuickPanel+) is a 12.1-inch SVGA industrial operator panel with combined visualization and embedded control functions. It adopts projected capacitive multi-touch TFT screen with 800×600 resolution, powered by 1GHz ARM Cortex-A8 processor, running Windows Embedded Compact 7. It is equipped with dual 10/100Mbps Ethernet ports, RS232/422/485 serial ports, USB and SD card slot, supporting multiple PLC protocols including SRTP, Modbus TCP and EGD. The front panel meets IP65 protection for panel mounting in industrial control cabinets. This HMI is supplied as new surplus or fully tested refurbished spare parts for factory automation, energy and process control retrofit projects.

Product Functions

• Real-time process visualization, trend graph display, alarm notification and recipe management
• Integrated control function, can run PAC control logic besides HMI display
• Dual Ethernet ports for network redundancy and separate control/office network isolation
• Multi-protocol communication with GE PACSystems and other mainstream PLC brands
• SD card and USB interface for program backup, restore and data logging export
• Support glove touch operation, remote access and maintenance via network

Application Scenarios

• Power plant boiler, turbine and auxiliary equipment control systems
• Petrochemical, oil & gas and water treatment process monitoring cabinets
• Packaging, textile, printing and metal processing automated production lines
• Material handling, test stands and custom machine control stations
• Spare replacement and upgrade of existing QuickPanel+ series HMI panels
