The PM 803F 3BDH000530R1 is a processor module (CPU module) in the ABB Freelance AC 800F controller series. Responsible for executing control logic,

processing input/output signals, and managing communication with fieldbus.

Product ID:3BDH000530R1

ABB model name :PM 803F

Table of Contents :PM 803F Base Unit 16 MB

Detailed description :PM 803F, Base Unit 16 MB, battery-buffered RAM

Product net depth: 164 millimeters

Product net height: 202 millimeters

Product net width :239 millimeters

Net weight of the product: 1.6 kilograms

Main features and functions

High-performance processor: As the central processing unit of the AC 800F controller, the PM 803F is capable of handling complex control tasks and large amounts of data.

Modular design: The AC 800F controller adopts a modular structure, with the PM 803F serving as the CPU unit. It can be connected to power modules, Ethernet modules,

and various fieldbus modules (such as the FI830F PROFIBUS-DP module) to meet different application requirements.

Redundancy support: Supports redundancy configuration at all levels, including processor redundancy,

thereby enhancing the availability and reliability of the system and ensuring the continuous operation of critical processes.

The PM 803F Base Unit of AC 800F consists of a housing and a CPU main board. This unit can be equipped with various modules. Comes without operating system. The operating system has to be loaded during software installation. With special Contact Ledge RW 855F. Software V7.1SP2a or higher is mandatory. Restrictions: The performance of PM 803F is 5 - 10% below the performance of PM 802F (Obsolete).

Extensive fieldbus support: The AC 800F controller supports all major fieldbuses in process automation applications, such as:

PROFIBUS-DP (Maximum speed up to 12 MBd)

FOUNDATION Fieldbus HSE (via LD 800HSE)

CAN (for Freelance Rack I/O

I/O point capability: A single controller can typically support approximately 1,000 I/O points.

Compact and robust design: The module design is compact and the structure is solid, making it suitable for harsh industrial environments.

Integrated engineering tools: Fieldbuses and connected field devices can be fully configured and parameterized through Freelance engineering tools without the need for additional external configuration tools.
