IS200EDEXG1BBB GE Mark VI EX2100 De-Excitation Control Board

Product Description
IS200EDEXG1BBB is GE Speedtronic Mark VI series de-excitation control board for EX2100 generator excitation control system. It executes crowbar de-excitation function, dissipates the stored magnetic energy of generator field winding during emergency trip or field breaker opening, suppresses dangerous overvoltage and protects excitation components and generator rotor. This board integrates SCR firing circuit, field current/voltage monitoring and fault detection circuits, communicating with other EX2100 boards through internal backplane connectors.

Key Features

• Designed for GE EX2100 / EX2100e excitation system under Mark VI turbine control platform
• 8 SCR firing channels for controlled field energy discharge and crowbar protection
• Built-in field voltage and current measurement, on-board fault diagnosis for overvoltage and circuit failure
• Multiple D-type and ribbon connectors for signal interconnection with EMIO, EPSM and other EX2100 cards
• Supports fast de-excitation sequence during turbine/generator emergency shutdown
• Onboard capacitors and power circuits for energy absorption and transient suppression
• Operating temperature: 0 ~ +60℃, rack-mounted PCB board for turbine excitation cabinet
• Legacy GE power generation control part; original production discontinued, mainly for spare replacement

Application Scenarios

• Steam turbine and gas turbine generator excitation control cabinets
• Power plant EX2100 excitation system maintenance and spare replacement
• Combined cycle power unit, thermal power generator set protection
• Industrial captive power plant generator field de-excitation protection retrofit

FAQ

Q: What is the main function of IS200EDEXG1BBB?
A: It controls generator field de-excitation, releases field stored energy quickly during trip to avoid rotor overvoltage damage.

Q: Which system does this board belong to?
A: GE Mark VI Speedtronic, matched with EX2100 / EX2100e excitation control system.

Q: Can it be hot swapped online?
A: Not hot-swappable; excitation system must be shut down and isolated before board replacement.
