ABB RDCU-12C 3AUA0000036521 ACS800 Drive Control Unit

Product Description
RDCU-12C, order code 3AUA0000036521, is the main control unit for ABB ACS800 series variable frequency drives. It serves as the core CPU board of the ACS800 inverter, responsible for motor vector control algorithm execution, I/O signal processing, parameter storage, fault diagnosis and communication management. This control board connects with power unit, operation panel and optional fieldbus adapters. It is equipped with digital and analog terminals for sensor signals, interlock and actuator control. The module adopts rack mounting inside the ACS800 inverter cabinet, widely used as OEM spare replacement part for industrial ACS800 drive maintenance and retrofit projects.

Key Functions

• Core vector control algorithm for ACS800 AC drive, supporting DTC Direct Torque Control
• Digital and analog I/O signal acquisition and output for external interlock and sensor connection
• Drive parameter storage, running status monitoring and fault alarm recording
• Support connection with ABB control panel for local parameter setup and status display
• Multiple fieldbus expansion interfaces for communication with PLC and DCS systems
• Real-time protection logic: overcurrent, overvoltage, overload, over-temperature monitoring
• Built-in hardware self-diagnosis for board circuit and peripheral signal fault detection
• Compatible with different power frame sizes of ACS800 series inverters

Application Scenarios

• ABB ACS800 series low and medium voltage variable frequency drive system
• Metallurgy, mining, paper mill, chemical plant large motor speed regulation
• Power plant auxiliary equipment, water treatment large pump and fan control
• Factory production line ACS800 inverter spare parts replacement and maintenance
• Industrial drive system renovation, upgrade and spare inventory backup

FAQ

Q: What series does RDCU-12C 3AUA0000036521 belong to?
A: It is the main control unit of ABB ACS800 series AC variable frequency drive.

Q: What control technology does it adopt?
A: DTC Direct Torque Control, ABB high-performance motor control technology.

Q: Can it communicate with external PLC?
A: Yes, it supports various optional fieldbus adapters for PLC and DCS communication.
