GE IC755CSW07CDA QuickPanel+ 7" HMI Operator Touch Panel

Product Description
IC755CSW07CDA is GE Fanuc QuickPanel+ series 7-inch widescreen industrial HMI touchscreen, running Windows Embedded Compact OS. It is equipped with Freescale i.MX535 1GHz ARM Cortex-A8 processor, 512MB DDR2 memory and 256MB SLC NAND flash storage. The panel features 800×480 WVGA projected capacitive 2-point multi-touch display, fanless natural cooling design, panel mount or VESA 75 mounting options. It integrates Ethernet, RS232 serial and dual USB2.0 ports, used for process visualization, operator control, data logging and alarm management, widely matched with GE PAC, RX3i series PLC systems.

Key Functions

• 7-inch widescreen TFT LCD, 800×480 resolution, projected capacitive dual-point touch
• i.MX535 1GHz ARM CPU, 512MB DDR2 RAM, 256MB SLC NAND Flash
• 1×10/100Mbps Ethernet RJ45, 1×RS232 COM, 2×USB2.0 Type-A interfaces
• Fanless passive cooling, high vibration and dust resistance for cabinet installation
• Support data trend graph, event alarm logging, user access permission management
• Built-in web browser, email/SMS alert function and remote diagnostic capability
• Panel cutout mounting, compatible with GE PACSystems control platform

Application Scenarios

• Factory automation, packaging machinery, material handling machine HMI operation
• Water treatment, power auxiliary system, oil & gas local process monitoring
• GE RX3i / PACSystems PLC system human-machine interaction
• Metallurgy, chemical, pharmaceutical industrial on-site operation station

FAQ

Q: What operating system does IC755CSW07CDA use?
A: Windows Embedded Compact OS.

Q: What is the screen size and resolution?
A: 7 inch wide screen, 800 × 480 WVGA.

Q: Does it support multi-touch?
A: Yes, projected capacitive two-point multi-touch supported.
