The IS420PFFAH1A is a FOUNDATION Fieldbus connection device developed by GE. Belongs to the Mark VIe series.

The Mark VIe Control FOUNDATION FieldbusTM link device is elaborately designed to meet the strict standards of FF-HSE Specification Class 42c,

ensuring optimal performance and compatibility in industrial control systems. Based on YMGK's previous sales experience,

this advanced device is powered by a 24V DC power supply and offers a series of customized functions designed to simplify data communication and system management.

Specification

Part Number: IS420PFFAH1A

Manufacturer: General Electric

Manufacturing country: The United States

Power supply: 24V dc ±20%

Power consumption: Typical value 200 mA

Dimensions: 47 x 131 x 111 mm (1.9 x 5.2 x 4.4 in)

Product type: Foundation fieldbus Link equipment

Supply status: In stock

Series: Mark VIe

Port configuration

A serial COM port: Specifically designed for redundant operations, it provides a reliable communication interface for serial devices.

One LAN port: Facilitates high-speed Ethernet (HSE) subnet connections and enables seamless integration with modern network infrastructure.

Four fieldbus H1 ports: This device is equipped with multiple H1 ports, which can accommodate various field devices and enhance the flexibility and scalability of the control system architecture.

Grounding mechanism

Separate grounding screw connection: In addition to the grounding wire required for power connection,

the connection device also includes a separate grounding screw connection to ensure a stable electrical grounding, thereby enhancing safety and reliability.

Gateway function

HSE and on-board port gateway: This device serves as a gateway between HSE and four on-board ports, facilitating seamless data exchange and communication among different network segments.

Link Master Station (LM) and System Management (SM) time publisher: For each port,

the link device simultaneously acts as a link master station (LM) and system management (SM) time publisher to ensure efficient network management and synchronization.

Compatibility

Redundancy support: This linked device supports simplex and hot backup redundancy operations, providing flexibility and reliability for system configuration.

In hot backup mode, two physically linked devices are interconnected using a serial RS-232 zero modem cable to form a logically linked device,

known as a redundant group. Redundant control information is shared through the RS-232 cable, thus achieving seamless synchronization between the main equipment and the auxiliary equipment.

Automatic failover mechanism: If the main equipment malfunctions, the auxiliary equipment will automatically take over the control to ensure continuous and uninterrupted operation.

This automatic failover mechanism can mitigate the impact of equipment failures on the overall system performance, thereby enhancing system reliability.

Redundant role switching: When a faulty linked device is replaced, it will be automatically configured to match the Settings of the primary device and act as an auxiliary device in the redundant group.

In addition, if an H1 segment connector is disconnected from the main link device, a role switch will only occur when there are two or more H1 devices on that segment.

This intelligent role switching mechanism optimizes redundancy management while ensuring the efficient utilization of system resources.
