DS200ADPAG1 Communication Board Origina New In Stock
- Part number：DS200ADPAG1
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Product: DS200ADPAG1 – GE Mark V ADPA Genius Adapter Communication Board
GE DS200ADPAG1 | Base Original Genius I/O Interface Card for Speedtronic Mark V Turbine Control System
DS200ADPAG1 is the original base revision ADPA Genius Adapter PCB from General Electric, belonging to the classic Speedtronic Mark V turbine control platform. It acts as the core communication bridge between the Mark V main CPU rack and remote Genius distributed I/O stations, realizing protocol conversion and bidirectional data transmission between rack backplane bus and Genius fieldbus. DS200ADPAG1 is the bare base board without suffix assembly revisions (A/ABB), while DS200ADPAG1A is its upgraded assembled version with reinforced components. It collects remote DI/DO/AI/AO signals, transmits turbine control commands to field I/O modules, and uploads real-time equipment status, alarm and fault data back to the main controller, widely used in gas/steam turbine unit distributed monitoring and interlock control systems.
Core Technical Specifications
- Part Number: DS200ADPAG1 | Brand: General Electric | Series: Speedtronic Mark V | Type: ADPA Genius Adapter Board
- Version Definition: Base bare PCB, no post-assembly revision suffix; DS200ADPAG1A is upgraded complete assembly variant
- Onboard Connectors: 40-pin main backplane port, 26-pin Genius bus port, 3-pin power terminal, 10-pin auxiliary signal terminal, all with anti-drop cable latches
- Internal Power Draw: +5VDC 6A from rack backplane; system auxiliary power 18–32VDC nominal 28VDC
- Communication Protocol: GE proprietary Genius fieldbus, high-speed real-time I/O data polling cycle
- Front Panel Indicators: 2 LED status lights (Hardware OK / Genius Link Fault) for real-time communication diagnosis
- Rack Compatibility: Single-slot plug-in card for standard Mark V control rack, matched with DS200CPUH1 main processor board
- PCB Protection: Standard conformal coating for dust, moisture and mild corrosive gas resistance
- Operating Temperature: -30°C ~ +65°C | Storage Temperature: -40°C ~ +85°C
- Anti-Interference Circuit: Built-in surge absorption and differential signal isolation circuit for power plant cabinet EMI suppression
- Certifications: CE, UL industrial safety and EMC anti-interference compliance
Main Functional Features
- Dual-bus signal conversion: Translate Mark V rack backplane parallel bus signals to Genius serial fieldbus for remote distributed I/O expansion
- Real-time cyclic data polling: Synchronously read remote digital/analog field signals and distribute main control valve regulation & interlock output commands
- Complete hardware self-diagnosis: Dual LED indicators quickly locate board power failure, Genius bus disconnection and communication timeout faults without testing tools
- Multi-terminal latch locking design, effectively prevent cable loose contact caused by cabinet vibration during long-term unit operation
- Full compatibility with all Mark V Genius series I/O modules (DIH, DOH, ADMA, ADCC, LDCCH series boards)
- Support simplex, dual redundant and TMR triple redundant turbine control architectures to improve overall system safety integrity
- Standard plug-in modular structure, power-off hot-swappable design for convenient spare part replacement during power plant maintenance
- Offline test terminals reserved for maintenance staff to measure bus signal voltage without disassembling wiring harnesses
Application Industries
- Combined Cycle & Thermal Power Plant: Mark V gas/steam turbine distributed Genius I/O communication control rack
- Oil & Gas Industry: Onshore gathering station and offshore platform turbine generator remote field signal acquisition system
- Industrial Cogeneration Station: Reciprocating engine generator set safety interlock distributed monitoring cabinet
- Metallurgy Plant: Heavy-duty drive auxiliary turbine unit remote valve and vibration signal collection equipment
- Equipment Retrofit & Maintenance: Spare replacement for aging Mark V turbine control communication interface boards
