TRICONEX 3504E 16-Channel Safety Analog Input Module for Tricon SIL 3 SIS

Product Description

The TRICONEX 3504E is a high-integrity Triple Modular Redundant (TMR) 16-channel analog input module, engineered by TRICONEX (Schneider Electric, former Invensys) for SIL 3 safety instrumented systems (SIS) in critical industrial environments. As a core safety signal acquisition component, this hot-swappable module (supplied as a TMR set of 3) is designed to collect 4-20 mA loop signals from field safety transmitters (pressure, temperature, level, flow) with high accuracy, channel-level diagnostics, and noise immunity. It features channel-to-channel and channel-to-ground isolation, TMR majority voting, and seamless integration with Tricon/Tricon CX chassis—making it ideal for emergency shutdown (ESD), fire & gas (F&G), and process safety systems in oil & gas, chemical, petrochemical, and power generation industries.

Key Functions

The 3504E analog input module delivers fault-tolerant, TMR-voted analog signal acquisition for safety-critical applications. Key functions include: 16 independent differential 4-20 mA current input channels (configurable for 0-20 mA); channel-to-channel and channel-to-ground isolation (2500 V AC optical isolation) to prevent ground loops and electrical noise interference; high-precision 16-bit A/D conversion; TMR majority voting (2-out-of-3) for data integrity; hot-swappable design for online maintenance without system shutdown; LED status indicators for module health, channel active status, and voting results; and compatibility with Tricon/Tricon CX main/expansion chassis.

Application Scenarios

The TRICONEX 3504E analog input module is deployed in safety-critical industrial applications requiring high-integrity analog signal acquisition with SIL 3 compliance. In offshore oil & gas platforms and refineries, it collects 4-20 mA signals from pressure transmitters, flow meters, and level sensors to monitor process parameters and trigger safety shutdowns. For chemical and petrochemical plants, it monitors reactor temperature transmitters, toxic gas detectors, and emergency isolation valve position feedback, ensuring coordinated safety actions and compliance with IEC 61508/61511 standards. In power generation facilities, it connects turbine/generator vibration sensors, cooling system temperature transmitters, and breaker control circuit feedback to Tricon SIS, supporting regulatory compliance and operational reliability. The module is also used in mining, pharmaceutical, and water/wastewater treatment—all scenarios where secure, high-availability analog signal acquisition is mandatory.

Technical Specifications
