Eaton‑Moeller XVS‑440‑10MPI‑1‑1U HMI‑PLC Product Description

The XVS‑440‑10MPI‑1‑1U belongs to Eaton Moeller XVS400 series 10.4‑inch infrared‑touch integrated HMI‑PLC unit, manufactured in Switzerland. It combines color TFT operator touch‑panel and embedded IEC‑61131‑3 PLC runtime on Windows‑CE platform, used for machine‑level visualization, local logic‑control, alarm‑event management and field‑bus communication. This hardware is end‑of‑life discontinued; only available as surplus/refurbished spare stock. Base OS firmware pre‑loaded; full HMI visualization project, PLC program and communication‑licenses must be downloaded via XSoft‑CoDeSys‑2 engineering software before commissioning. Gross weight approx 2.1 kg.

Product Features

• 10.4‑inch VGA 640×480 TFT infrared touch‑screen; 65536‑color display; supports recipe storage, real‑time trend‑graph and timestamped alarm‑logging for industrial machinery.
• Embedded PLC runtime compliant with IEC‑61131‑3 standard; supports LD / FBD / ST programming languages, executes interlock‑logic, timing‑counting and batch‑sequence control; PLC function requires valid software license activation.
• Built‑in interfaces: 10/100 Ethernet, PROFIBUS‑MPI, RS232, USB‑Host / USB‑Device; supports Modbus‑TCP, MPI‑protocol for connection to drives, remote‑I/O and third‑party PLC systems.
• NEMA12 front‑panel rating; panel‑mount metal housing; wide‑range 24 VDC operating supply; conformal‑coated PCB for vibration‑prone industrial‑site environment.
• Comprehensive onboard self‑diagnosis: monitors touch‑controller, communication‑link, internal temperature; fault‑buffer stores timestamped error records for post‑failure root‑cause analysis.
• XVS‑440‑10MPI‑1‑1U is dedicated hardware variant; hardware‑revision, memory allocation and firmware baseline must match original project; cannot freely swap‑in with XVS‑440‑10MPI‑1‑10 without full project‑validation test.
• Pre‑installed Windows‑CE base system; HMI project, PLC control‑logic, communication‑parameters and license‑keys must be downloaded; missing configuration leads to loss‑of‑control risk.

Application Scenarios

• Packaging‑machinery, printing‑production‑lines integrated operator‑control‑HMI‑PLC spare‑part‑replacement projects.
• Plastic‑injection‑molding‑machines, rubber‑processing‑equipment local stand‑alone automation‑control stations.
• Water‑treatment plant, material‑handling‑system small‑scale machine‑control cabinet retrofits.
• Retrofit‑maintenance for existing production‑plants equipped with aging XVS400‑series HMI‑PLC hardware.
