WOODWARD 8237-1603 ProTechTPS Bulkhead Mount TMR Overspeed Protection System

Product Brief Description

Woodward 8237-1603 is the ProTechTPS bulkhead-mounted triple modular redundant overspeed protection system with voted relay outputs, designed for rotating machinery safety instrument systems. Built on TMR architecture with 2-out-of-3 voting logic, it continuously monitors shaft speed from three independent speed transducers. When overspeed, over-acceleration, sensor fault or loss-of-speed events are detected, it triggers safety trip action via voted relay circuits. This standalone safety unit is physically mounted directly on turbine/compressor skids, independent of the turbine governor. It supports local HMI viewing, time-stamped event logging and Modbus RTU communication, widely stocked as safety spare for gas turbines, steam turbines and high-speed compressors.

Product Features & Functions

• Triple Modular Redundant (TMR) design with three independent speed channels, 2oo3 voted trip relay outputs
• Bulkhead mount sealed enclosure for field installation directly on rotating machinery skids
• Compatible with passive magnetic pickups (MPU) and active proximity probes for shaft speed measurement
• Detects overspeed, high acceleration, speed loss, open/short cable faults and cross-channel mismatch alarms
• Voted relay trip outputs for emergency shutdown circuits, providing higher integrity than individual relays
• Integrated front HMI and keypad for local speed display, setpoint configuration, alarm and fault browsing
• Modbus RTU interface for transmitting real-time speed, alarm and diagnostic data to DCS/SCADA systems
• High-capacity event recorder to store time-stamped trip sequences and alarms for post-fault root-cause analysis
• Continuous cross-channel self-diagnostics for sensors, wiring and internal electronics health monitoring
• Configured for HV/LV relay specification, suitable for a wide range of ESD emergency shutdown circuits

Application Scenarios

• Steam turbine and gas turbine overspeed safety protection for power generation plants
• High-speed centrifugal compressors, expanders and rotating equipment on oil & gas skids
• Cogeneration CHP plants and captive power stations requiring high-integrity SIS protection
• Refinery, chemical and pulp & paper industrial rotating machinery safety instrumented systems
• Preventive maintenance spare replacement, safety system retrofits and turbine upgrade projects
