Corcom / TE 10VV1/F7252 EMI Line Filter Product Description

10VV1/F7252 (Corcom 10VV1 series, TE Connectivity part number 6609043-3) is a single-phase EMI power line filter, widely deployed inside servo drives, CNC machine control cabinets, industrial instruments and automation equipment. It suppresses conducted electromagnetic interference on AC power lines, prevents external mains noise from disturbing internal control circuits and blocks noise generated by power electronics from feeding back to the grid. With Faston quick terminals and compact metal housing, this filter is stocked as fully tested spare replacement component for legacy automation cabinet maintenance.

Product Features

• Single-phase EMI filter, rated current: 10A, rated voltage: 120/250VAC, 50/60Hz
• Metal shield enclosure for high attenuation of common-mode and differential-mode noise
• Faston 0.25" quick connect terminals for simple wiring installation
• Low leakage current design: max 0.5mA@120VAC, 0.82mA@250VAC
• Built-in safety capacitance and inductor components for power noise filtering
• Compact size, chassis mount design for installation inside control cabinet
• UL safety certified, suitable for industrial control, CNC and servo equipment
• High vibration resistance for factory machine tool cabinet environments
• Low power consumption, passive filter without external control power needed

Application Scenarios

• Indramat / Rexroth servo drive and spindle drive cabinet power input filtering
• CNC machining center, milling machine, grinder control panel power filtering
• Industrial automation controllers, PLC, HMI and test equipment power supply filtering
• Packaging machinery, robotic workcell electrical cabinet EMC improvement
• Medical equipment and precision instrument AC line noise suppression
• Replacement spare for old industrial cabinets with EMI filter failure
