Reliance 0-52712 (800756-21B) 115VDC Dual Output Card

Short Description: Reliance 0-52712 with marking 800756-21B is a legacy 115VDC dual output PCB card for Reliance Electric industrial DC drive systems. It delivers isolated drive output signals and handles power switching functions for motor control loops. Featuring an angled PCB profile with handle cutout, integrated MOV surge protection and passive filter components, it is a discontinued spare part for old Reliance drive racks, widely used for retrofit and replacement of existing heavy-duty drive equipment.

Product Functions

• Dual channel 115VDC output switching for DC drive control circuits
• Surge suppression by built-in MOV varistors and filter capacitors to absorb voltage spikes
• Signal conditioning and isolation between main drive controller and field auxiliary loads
• Converts low-level control commands into high-side DC drive output signals
• Protects drive control board from back EMF generated by relay and solenoid loads
• Direct slot mount into Reliance legacy drive rack with quick pull-out handle design
• Passive and active component assembly for stable long-running operation under industrial cabinet conditions

Application Scenarios

• Reliance legacy DC motor drive control racks
• Metal rolling mills, extrusion machinery and heavy metal processing lines
• Paper machines, large conveyor systems and mine hoist drive cabinets
• Legacy industrial drive system retrofitting and spare part replacement projects
• Heavy manufacturing equipment with DC speed regulation control
• Plant maintenance for existing Reliance Electric drive installations
