716-140236-003 VM600 IOC4T Mk2 Rear Terminal Signal Card

1. Product Description

716-140236-003 is the factory part number of IOC4T Mk2 rear terminal IO card exclusively matched with Meggitt MPC4 Mk2 front machinery protection card for VM600 Mk2 rotating machinery monitoring system. It is a single-slot rear daughter card installed directly behind each MPC4 Mk2 in ABE040 / ABE042 6U 19-inch VM600 rack, serving as the dedicated physical wiring interface for vibration, displacement and speed sensors.

• 4 channels of dynamic signal input for eddy current proximity probes, IEPE accelerometers and velocity sensors; 2 independent tachometer/speed input channels for rotational speed measurement.
• 48-position screw terminal block for all field sensor wiring, integrated shield grounding terminals to eliminate ground loop noise in power plant cabinets.
• On-board 4 built-in programmable alarm relays and 32 open-collector digital outputs for local alarm indication or interlock with RLC16 relay output cards via rack internal bus.
• Full surge and EMI isolation circuits for all input/output circuits, conformal coated PCB to resist dust, humidity and corrosive gas inside industrial control cubicles.
• Slave communication via Industry Pack IP bus with front MPC4 Mk2, supports hot-swap replacement without powering off the entire rack in redundant monitoring systems.

• Provides buffered raw analog sensor signal outputs for on-site oscilloscope calibration and troubleshooting of vibration channels.




2. Core Product Functions

• Sensor Signal Routing Interface: Transmit raw vibration, shaft displacement and speed signals from field transducers to the front MPC4 Mk2 protection card for digital filtering, integration and alarm threshold calculation.
• On-board Alarm Relay Output: Trigger internal 4-channel relays when vibration reaches Alert/Danger levels, output hard-wired alarm signals to local panel indicators or auxiliary interlock circuits.
• Digital Interlock Signal Expansion: 32 open-collector outputs transmit multi-level alarm status to RLC16 relay cards for machine trip hard contacts to unit DCS safety interlock system.
• Electrical Noise Isolation & Protection: Built-in optocoupler and surge suppression components block high-frequency EMI interference from nearby high-power excitation cabinets and high-voltage switchgears.
• Sensor Power Distribution: Supply regulated negative DC power to eddy current probes via terminal block, with wire break detection function to report probe cable faults to MPC4.
• Field Calibration Interface: Buffered analog output terminals allow technicians to measure real-time vibration waveforms without disconnecting sensor cables during on-site commissioning.

3. Typical Application Scenarios

• Thermal power plant steam turbine-generator VM600 monitoring racks, paired with MPC4 Mk2 to monitor shaft vibration, axial thrust displacement and rotational overspeed, cooperating with BHEL UN series AVR excitation control cabinets.
• Combined cycle gas turbine units for high-speed rotor vibration protection and condition monitoring.
• Large hydroelectric generating sets for shaft radial vibration, bearing displacement and turbine speed supervision.
• Petrochemical, steel and mining heavy-duty rotating equipment: centrifugal compressors, large blowers and pump trains.
• Onshore and offshore captive power generation auxiliary machinery monitoring cubicles under severe EMI and high humidity environments.
