PathTrak CPU-5500 is the core single-board CPU module manufactured originally by JDSU (later VIAVI Solutions, ARRIS) exclusively for the PathTrak HFC return-path monitoring system, compatible with HCU1500, HCU400 series monitoring chassis. This rack-mount plug-in module acts as the master processing unit that manages all RPM series RF spectrum receiver cards installed in the same chassis, serving as the bridge between local RF measurement hardware and remote network operation centers (NOC). Powered via the chassis internal backplane without external power adapters, it integrates embedded industrial processor, local storage, 10/100Mbps Ethernet port and RS232 debug serial port. The unit collects real-time upstream RF spectrum data, QAM signal metrics, ingress noise and CPD (Common Path Distortion) readings from all monitoring modules, processes raw RF data locally and stores long-term historical trending logs. Equipped with conformal coated circuit board, front-panel status LED indicators, and full EMC shielding, it adapts to continuous 24/7 operation in cable TV headend equipment rooms with operating temperature ranging from 0°C to +50°C. It supports remote firmware upgrades, SNMP network management protocol and browser-based local web access, and is a field-replaceable hot-plug compatible spare module for legacy PathTrak monitoring racks widely deployed by broadband cable operators globally.

• Chassis master control: Schedule, synchronize and coordinate all RPM RF receiver modules to perform periodic upstream spectrum scanning
• Real-time RF data aggregation: Collect spectrum traces, signal power, noise floor, QAM modulation error and ingress interference data from every monitoring slot
• Local data storage and trending: Cache short-term real-time readings and archive long-term historical performance logs for fault root-cause analysis
• Configurable threshold alarm engine: Generate real-time alerts when RF noise, signal attenuation or CPD distortion exceeds user-defined limits
• Dual communication interfaces: RJ45 Ethernet for TCP/IP connection to NOC monitoring servers; RS232 serial port for local on-site debugging and configuration
• Web-based local management: Built-in web server to view live spectrum graphs, adjust scan schedules and export fault reports without dedicated software
• SNMP v1/v2c network protocol support: Seamless integration with operator NMS, OSS and central monitoring platforms for unified network visibility
• Remote firmware update: Complete module firmware upgrade via Ethernet without removing hardware from the chassis rack
• Comprehensive hardware self-diagnosis: Detect backplane communication failure, receiver module offline, storage error and internal overheating with LED status indication
• Event logging system: Record timestamped fault alarms, system restarts, configuration changes and RF abnormal events for audit and troubleshooting

• Backplane power management: Monitor chassis input voltage and distribute control signals to all peripheral RF measurement modules stably

• Cable TV HFC Headend Facilities: Centralized upstream return-path spectrum monitoring for DOCSIS cable broadband networks
• Broadband Network Operation Centers (NOC): Real-time remote monitoring of thousands of fiber node return paths across regional service areas
• Cable Network Maintenance Teams: Preemptive detection of ingress noise, impulse interference and CPD distortion to reduce field service truck rolls
• FTTH Hybrid HFC Convergence Networks: Monitoring upstream RF signals for combined video, internet and VoIP triple-play services
• Large Municipal Cable Operators: Multi-chassis PathTrak system deployment for city-wide plant RF performance surveillance
• Network Fault Troubleshooting Labs: Historical RF trend analysis to locate intermittent upstream signal degradation and hidden interference sources
• Legacy HFC System Retrofit: Replacement CPU spare module for aging PathTrak monitoring racks during cable network equipment upgrade projects

• Data & Video Broadcast Headends: Quality assurance monitoring for return-path telemetry and upstream customer modem signaling

• Q: The PathTrak CPU-5500 front status LED shows red fault light after chassis power-on?
  A: Typical causes include loose backplane connection between CPU and chassis, unrecognized RPM receiver modules, corrupted firmware, internal storage failure or abnormal chassis input voltage; run serial port self-test via RS232 to locate specific faults.
• Q: NOC server cannot pull RF monitoring data from CPU-5500 via Ethernet?
  A: Verify Ethernet cable integrity, correct static IP/subnet gateway configuration, SNMP community string matching, and ensure no firewall blocks the TCP/SNMP ports between headend and NOC.
• Q: Can CPU-5500 be hot-swapped while the PathTrak chassis remains powered?
  A: Limited hot-swap support is available, but full power-off of the chassis is recommended before replacement to avoid temporary loss of all RF monitoring data and backplane bus communication errors.
• Q: No spectrum data is displayed on the web interface after all RPM modules are installed normally?
  A: Check scan schedule configuration on the CPU web page, confirm the target frequency band is enabled, restart the CPU service via local serial debug port, and verify backplane communication handshake with receiver cards.
• Q: Historical trending logs disappear after chassis power cycle?
  A: Internal local storage may suffer read/write failure; re-flash official stable firmware, clear corrupted log partitions via RS232 command, or replace the CPU module’s internal storage component.
• Q: Is PathTrak CPU-5500 still in active production by VIAVI/ARRIS?
  A: This module has been discontinued; only refurbished, surplus or used spare units are available for maintenance of legacy HFC monitoring systems. New deployments adopt modern VIAVI return-path monitoring platforms instead.

• Q: CPU-5500 generates excessive false ingress noise alarms constantly?
  A: Adjust RF threshold parameters on the web management page, extend spectrum scan averaging time, filter out temporary impulse noise, and calibrate connected RPM RF receiver modules.
