1. Product Description

1VCF752000 is the complete part number of ABB REF542PLUS, a high-performance feeder protection and control unit belonging to the Relion 650 series. Designed for medium-voltage switchgear panels, this all-in-one device integrates fault protection, electrical measurement, local/remote circuit breaker control, fault recording and multi-protocol communication. It features a metal enclosure with IP20 indoor protection, wide operating temperature range and full EMC compliance to meet industrial power grid standards. The unit supports IEC 61850 digital substation communication and serves as core secondary equipment for thermal power plants, industrial power distribution systems and utility substations.

• Part Number: 1VCF752000, Model: REF542PLUS
• Product Series: ABB Relion 650 protection relay family
• Power Supply: AC/DC 220V, maximum power consumption ≤20W
• Rated Short-Time Withstand Current: 31.5kA, applicable for 10kV / 35kV medium voltage switchgear
• Operating Temperature: -25°C ~ +70°C; Storage Temperature: -40°C ~ +85°C
• Protection Class: IP20 (cabinet indoor installation), IEC 61000-4 EMC anti-interference standard
• Dimension: 192(W) × 114(H) × 72(D) mm, net weight 1.5kg

• Interfaces: Dual Ethernet ports, RS485 bus, multi-channel DI/DO, 4-20mA analog input, expandable ST fiber optic port




2. Core Product Functions

1. Comprehensive Feeder Fault Protection Logic: Equipped with three-stage overcurrent protection, residual earth fault protection, overload protection, overvoltage/undervoltage protection, phase-to-phase short-circuit protection and circuit breaker failure protection. It triggers rapid tripping within milliseconds to isolate faulty feeders and guarantee power system safety.
2. High-precision Electrical Parameter Measurement & Metering: Continuously collects three-phase voltage, current, active/reactive power, power factor and accumulated energy. The built-in multi-function energy meter supports energy consumption statistics and power settlement.
3. Local & Remote Circuit Breaker Control: Supports manual close/trip via front panel buttons and remote control through SCADA/DCS system. Monitors circuit breaker position, spring charging status and trip/close coil signals in real time.
4. Multi-protocol Industrial Communication Networking: Ethernet supports IEC 61850 and DNP3.0; RS485 interface runs Modbus RTU protocol. Redundant fiber ring network is available for data transmission to PLC, GE Mark VIe and monitoring platforms.
5. Fault Wave Recording & SOE Sequence of Events Logging: Stores waveform data before and after faults, switch position changes and protection operation records. Time synchronization via SNTP or IRIG-B clock source for accurate fault tracing.
6. Continuous On-board Self-diagnosis: Real-time monitoring of power supply, analog acquisition circuits, communication channels and internal chips. It outputs fault alarm signals to upper monitoring system automatically once hardware or channel abnormalities are detected.

3. Application Scenarios

• 10kV auxiliary power feeder protection for thermal power plants and combined cycle gas turbine power stations, matched with Woodward governors, Bently vibration monitoring and GE unit control systems
• 10kV / 35kV distribution substation, ring main unit and box-type transformer feeder protection and measurement
• Medium voltage power distribution rooms for chemical plants, cement factories, mines and large manufacturing facilities
• Power generation distribution systems on offshore platforms and marine vessels with wide temperature and anti-vibration requirements
• Bay-level secondary protection devices for digital intelligent substations, complying with national power grid access standards
