RELIANCE S-D4039 Control Card Origina New In Stock
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Product: RELIANCE S-D4039 SRCS-1 – Reliance PSC7000 CompactPCI Serial Communication Control Card
Reliance Electric S-D4039 (SRCS-1) | High-Speed Serial Communication Master Card for PSC7000 Motion Control Rack
RELIANCE S-D4039 SRCS-1 is a CompactPCI serial communication master card developed by Reliance Electric (ABB Baldor-Reliance), specially matched with the PSC7000 multi-axis motion control platform. As the core communication gateway of the rack, it realizes high-speed serial data exchange between the main CPU, motion axis cards (MCIM-2 S-D4043-D), external HMI, upper DCS and peripheral drive equipment. Equipped with independent TX/RX fiber differential communication circuits, it supports proprietary Reliance serial bus and standard industrial serial protocols, completes real-time motion parameter upload, program download and fault alarm data transmission, and is widely used in paper, metallurgy and film production line multi-axis synchronous control systems.
Core Technical Specifications
- Model: S-D4039 SRCS-1 | Brand: Reliance Electric | Bus Standard: CompactPCI PSC7000 Series
- Product Type: Serial Communication Master Control Card with Fiber Transceiver
- Front Interface: TX/RX fiber optical communication port, front panel CPU OK / LINK status LED indicators
- Communication Rate: High-speed differential serial bus, microsecond-level real-time data transmission cycle
- Rack Compatibility: Standard slot installation inside PSC7000 CompactPCI control rack, matched with S-D4012 backplane
- Backplane Power Supply: Rack internal 5VDC industrial power, low power consumption design
- Supported Matching Modules: MCIM-2 motion control card, DIO digital I/O card, AIO analog acquisition card
- Operating Temperature: -20°C ~ +60°C | Storage Temperature: -40°C ~ +85°C
- Ambient Condition: 0%~90% non-condensing humidity, anti-vibration industrial grade
- Circuit Protection: Full conformal coating, dust, moisture and corrosive gas resistance
- Certifications: CE, UL industrial EMC anti-interference safety compliance
Main Functional Features
- Fiber differential serial communication design, effectively isolate electromagnetic interference in high-power drive cabinet environments to ensure stable long-distance data transmission
- Centralized communication scheduling function, uniformly manage data interaction between rack CPU, multi-axis motion cards and external upper monitoring systems
- Support online program download, motion curve parameter modification and real-time trend data upload without system shutdown
- Complete hardware self-diagnosis function, front panel LED quickly locate communication disconnection, fiber fault and module hardware abnormalities
- Hot-swappable CompactPCI plug-in structure, can be replaced separately during equipment maintenance without stopping the whole production line control rack
- Perfectly matched with S-D4012 5-slot backplane and MCIM-2 motion control card, forming a complete multi-axis synchronous motion control system
- Built-in data cache circuit, avoid data loss caused by instantaneous power fluctuation during continuous production operation
- Compatible with Reliance PSC motion programming software, convenient communication channel configuration and fault log export analysis
Application Industries
- Paper Industry: Paper machine winding/unwinding multi-axis constant tension synchronous control cabinet
- Metallurgy Industry: Steel strip slitting, leveling rolling mill multi-servo positioning control equipment
- Film & Coating Production: Multi-layer coating machine high-precision linkage motion control system
- Printing & Packaging: Gravure printing machine electronic line shaft multi-axis synchronous drive control
- Industrial Equipment Retrofit: Maintenance and replacement of legacy Reliance PSC7000 old motion control systems
