Reliance MCIM-2 S-D4043-D Master Card Origina New In Stock
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Product: Reliance MCIM-2 S-D4043-D – PSC CompactPCI SERCOS Motion Interface Master Card
Reliance Electric MCIM-2 (S-D4043-D) | Multi-Axis SERCOS PG Pulse Encoder Motion Control Module for PSC7000 System
Reliance MCIM-2 S-D4043-D is a CompactPCI standard motion interface master module developed by Reliance Electric (ABB Baldor-Reliance), matched with PSC7000 industrial motion control platform. It serves as the core SERCOS communication and PG encoder signal processing card, integrating 5 independent axes of encoder pulse input and high-speed SERCOS bus master communication function. It collects two-phase 90° differential pulse + Z-phase zero mark signals from servo motor encoders, executes high-precision position closed-loop calculation, and realizes real-time synchronous control of multiple servo drives through SERCOS optical bus. Two MCIM-2 cards can be installed in one PSC7000 rack to expand up to 10 axes of independent motion control, widely used for multi-axis synchronous tension and positioning control of papermaking, metallurgical slitting and coating production lines.
Core Technical Specifications
- Model: MCIM-2 S-D4043-D | Brand: Reliance Electric | Bus Standard: CompactPCI PSC Series
- Core Function: SERCOS bus master + 5-channel PG encoder signal acquisition module
- Axis Expansion: Single card supports 5 independent servo axes; max 2 cards per rack for 10-axis total control
- Encoder Signal Support: 90° phase difference A/B pulse + Z index pulse, compatible 5V/12V encoder power supply
- SERCOS Interface: Standard SERCOS optical fiber communication port, high-speed real-time motion data transmission
- Encoder Input Impedance: 300Ω (5V system) / 1.1kΩ (12V system), built-in signal isolation circuit
- Rack Matching: PSC7000 CompactPCI control rack, installed in slot 1 or slot 2
- Backplane Power: Rack 5VDC industrial power supply, single module power consumption ~164g
- Operating Temperature: -20°C ~ +60°C | Storage Temperature: -40°C ~ +85°C
- Front Interface: DB9 SERCOS communication port + rear terminal block for encoder wiring
- Certifications: CE, UL industrial EMC anti-interference safety compliance
Main Functional Features
- 5-channel independent encoder signal acquisition, supports dual voltage level encoders (5V/12V) for flexible on-site equipment matching
- Integrated SERCOS bus master controller, realizes high-speed synchronous communication between main control unit and multi-axis servo drives
- High-precision pulse counting and position closed-loop calculation, supports constant tension, electronic line shaft and multi-axis synchronous positioning algorithms
- Built-in complete channel self-diagnosis function, automatically detect encoder disconnection, short circuit and SERCOS communication fault alarms
- Fiber optic SERCOS transmission design, effectively suppress strong electromagnetic interference in high-power drive cabinet environments
- Compact CompactPCI hot-swappable plug-in structure, can be replaced without full rack shutdown during equipment maintenance
- Full conformal coating circuit board, dust-proof, moisture-proof and anti-corrosion, adapting to harsh factory production environments
- Fully compatible with PSC7000 motion control programming software, convenient axis parameter calibration, motion curve editing and fault waveform recording
Application Industries
- Paper Industry: Paper machine winding/unwinding multi-axis synchronous tension control system
- Metallurgy Industry: Steel strip slitting, leveling and rolling mill multi-servo positioning control equipment
- Coating & Film Production: Multi-layer film coating machine high-precision synchronous drive control cabinet
- Printing & Packaging: High-speed gravure printing machine electronic line shaft multi-axis linkage control
- Industrial Equipment Retrofit: Maintenance and replacement of legacy Reliance PSC7000 motion control systems
Product Picture
