• Part Number:3BSE091722R1
• ABB Model Name:LD 810HSE EX
• Catalog Description:LD 810HSE Explosion-Proof Connection Unit
• Detailed Description:LD 810 HSE EX module for DIN rail mounting, equipped with 4 H1 connection terminals and one HSE connector. The module requires an external 24VDC power supply. The H1 terminals must be powered separately.Restriction: The LD 810HSE Ex connection unit cannot be used to replace LD 800 connection units within a redundant pair. Specifically, both connection units in a redundant pair must be replaced with LD 810HSE Ex. Redundant cables for LD 810HSE Ex can be fabricated or purchased by end customers independently and do not need to be ordered via ABB.




• ABB Product Series:S900 IO Hardware
• ABB Model Designation:LD 810HSE EX
• CN8 Code:85176200
• Country of Origin:Germany, United States
• Customs Tariff Code:85176200
• HS Code Explanation (851762):Electrical machinery and equipment and parts thereof; sound recorders and reproducers, television image and sound recorders and reproducers, and parts and accessories of such articles; Telephones, including smartphones and other telephones for cellular or other wireless networks; Other apparatus for transmitting or receiving voice, images or other data, including apparatus for communication over wired or wireless networks (e.g. local area networks or wide area networks), excluding transmitting or receiving apparatus falling under headings 8443, 8525, 8527 or 8528; Machines for receiving, converting, transmitting or reproducing voice, images or other data, including switching and routing equipment.
• Invoice Description:LD 810HSE Explosion-Proof Connection Unit
• Component Condition:New
• Product Type:Communication Module
• Net Product Depth:105 mm
• Net Product Height:100 mm
• Net Product Weight:0.25 kg
• Net Product Width:35 mm
• Product Application Category:Communication Module
• Warehouse Stock Locations:Västerås, SwedenWickliffe, Ohio, United StatesMenden, GermanySingapore, SingaporeVästerås, Sweden

• Bi-directional data republishing: transfer process data between H1 links, and mutual data forwarding between H1 and HSE networks
• Full remote management: identify, configure and access function blocks of all H1 field devices via HSE Ethernet from central control room
• Integrated LAS link scheduling for each H1 channel, stable publisher/subscriber real-time data transmission
• Complete alarm & event distribution, upload all field device fault signals to upper DCS system
• Galvanic isolation on four H1 ports to eliminate cross-channel interference and improve system stability
• Explosion-proof EX design, suitable for Zone 1/2 hazardous locations with flammable gas and vapor
• Compact DIN rail modular design, easy wiring, installation and on-site replacement maintenance
• Perfect compatibility with ABB System 800xA DCS and full series FOUNDATION Fieldbus instruments

• Petrochemical & Refinery: Hazardous area process control, furnace and pipeline fieldbus communication
• Oil & Gas: Onshore & offshore platform automation, gas transmission station monitoring systems
• Chemical Industry: Explosive production workshop FOUNDATION Fieldbus control network
• Pharmaceutical: Flammable solvent production process automation
• Power Plant: Hazardous fuel handling area DCS fieldbus expansion
