KUC720AE01 3BHB003431R0101 Excitation Control Board-KIMI

Part number：KUC720AE01 3BHB003431R0101 3BHB000652R0101
Product Origin：Sweden
HS CODE：85413000
Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ABB KUC720AE01 3BHB003431R0101 Excitation Control Board

ACS1000 Series - Core Control Component for Medium-Voltage Inverter Excitation Systems

1. Product Overview

The ABB KUC720AE01 3BHB003431R0101 is a dedicated excitation control board designed for ABB ACS1000 medium-voltage (MV) inverter systems, acting as the core component to regulate and control the excitation current of power semiconductor devices (IGBTs) in MV drives. It integrates precise current regulation, real-time status monitoring, and fault protection functions, ensuring stable and efficient operation of the inverter's excitation system. With compatibility for multiple communication protocols and seamless integration with ACS1000 control units, the board provides reliable excitation control for industries such as power generation, oil & gas, mining, and heavy industry where MV drive stability is critical.

ABB KUC720AE01 3BHB003431R0101 3BHB000652R0101 (3).png

产品ID:3BHB003431R0101

ABB型号名称:KU C720 AE

目录说明:KU C720 AE; ELECTRONIC POWER EPS

详细描述:KU C720 AE

更换产品ID（OLD）:

HB003431R0101

3BHB003431R0001

技术信息:This board is obsolete. Please contact SRU MV Drives Turgi for replacement.

Key Specifications

• Model: KUC720AE01 | Ordering Code: 3BHB003431R0101 | Brand: ABB | Series: ACS1000 MV Inverter

• Type: Excitation Control Board for Medium-Voltage Inverter IGBT Excitation Systems

• Input Voltage: 24V DC (18-32V DC) | Power Consumption: 12W (Typical)

• Excitation Current Regulation Range: 0-5A (Adjustable) | Regulation Accuracy: ±0.5%

• Communication Interfaces: Profibus DP, Modbus RTU, Ethernet (TCP/IP) | Data Transfer Rate: 12Mbps (Max)

• Control Functions: Excitation Current Regulation, Overcurrent Protection, Overtemperature Protection, Fault Diagnosis

• Isolation: Channel-to-Channel 500V AC; Board-to-Ground 1500V AC (1min)

• Operating Temperature: -20°C to +60°C | Storage Temperature: -40°C to +85°C

• Relative Humidity: 5% - 95% (Non-Condensing) | Protection Class: IP20 (Front Panel)

• MTBF: >100,000 Hours | Dimensions: 220mm (W) × 180mm (D) × 30mm (H)

• Weight: 0.85 kg | Installation: Cabinet Mounting (DIN Rail Compatible)

• Status Indicators: Power (Green), Run (Green), Fault (Red) LEDs

• Protection Features: Overcurrent, Overtemperature, Undervoltage Lockout (UVLO)

KUC720AE; 3BHB003431R0101.png

2. Core Features

• Dedicated for ACS1000: Optimized for IGBT excitation control in ABB medium-voltage inverters

• High-Precision Regulation: ±0.5% current accuracy ensures stable IGBT switching performance

• Multi-Protocol Communication: Profibus DP, Modbus RTU, and Ethernet for seamless system integration

• Comprehensive Protection: Overcurrent, overtemperature, and undervoltage protection to prevent board damage

• Status Monitoring: LED indicators for real-time power, run, and fault status visualization

• DIN Rail Compatible: Easy installation and replacement in control cabinets

• Fault Diagnosis: Built-in self-diagnostic functions for quick troubleshooting and maintenance

• Wide Operating Voltage: 18-32V DC input for compatibility with various industrial power supplies

ABB KUC720AE01 3BHB003431R0101 3BHB000652R0101.png

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders

3. Typical Applications

• Power Generation: Excitation Control for MV Pump and Fan Drives in Thermal Power Plants

• Oil & Gas: Inverter Excitation Regulation for Compressor and Pipeline Pump Drives

• Mining: IGBT Excitation Control for Conveyor Belt and Hoist MV Drive Systems

• Heavy Industry: Excitation System Control for Rolling Mill and Extruder MV Drives

• Water & Wastewater: Stable Excitation for Large-Account Pump MV Inverters

4. Installation & Maintenance

Installation: Mount on DIN rail or cabinet panel; Connect 24V DC power supply; Wire communication interfaces (Profibus/Modbus/Ethernet); Connect to ACS1000 control unit; Configure excitation current parameters via ABB Control Software; Test current regulation and communication status.

Maintenance: Daily - Check status LEDs (Power: Green, Run: Green, Fault: Red); Weekly - Inspect terminal connections and power stability; Annual - Clean dust, verify isolation performance, and update firmware.

Safety Notes: De-energize before wiring; Use ESD protection during handling; Follow ABB MV drive safety guidelines for high-voltage isolation.

KUC720AE; 3BHB003431R0101 ELECTRONIC POWER EPS(图2) 3BHB003431R0101.pdf
