UNIOP ETT-VGA-0045 Industrial VGA Display Output Module-KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

UNIOP ETT-VGA-0045 Industrial VGA Display Output Module

VGA Interface Module for HMI, Industrial Control & Monitoring Systems

1. Product Overview

The UNIOP ETT-VGA-0045 is a dedicated industrial VGA display output module designed for seamless integration with UNIOP HMI systems and industrial controllers, providing reliable analog video output for real-time data visualization, process monitoring, and operator control. Featuring a standard DB15 VGA port, it supports multiple resolutions (640×480, 800×600, 1024×768) to adapt to various industrial displays, monitors, or projectors, ensuring clear image rendering in harsh industrial environments. With 5V DC backplane power supply, -20°C to +70°C operating temperature range, and IP20 protection, the module delivers stable performance for applications in manufacturing, process control, energy, and building automation, enabling efficient operator-machine interaction and remote monitoring.

UNIOP ETT-VGA-0045 (2).png

Key Specifications

• Model: ETT-VGA-0045 | Brand: UNIOP (EXOR) | Type: Industrial VGA Display Output Module

• Interface: DB15 VGA Analog Video Output (for external displays/monitors)

• Supported Resolutions: 640×480, 800×600, 1024×768 (adjustable via system settings)

• Power Supply: 5V DC (from UNIOP backplane, no external power needed)

• Operating Temperature: -20°C to +70°C | Storage Temperature: -40°C to +85°C

• Protection Class: IP20 | Mounting: Standard UNIOP Backplane Slot

• Dimensions: 100mm(W)×120mm(D)×25mm(H) | Weight: ~150g

• Compatibility: UNIOP HMI Systems, Industrial Controllers, PLC-Based Control Panels

UNIOP ETT-VGA-0045 (4).png

2. Core Features

• Standard VGA Output: DB15 port for universal connection to industrial displays/monitors

• Multi-Resolution Support: Adapt to different screen sizes for flexible visualization

• Backplane Power: 5V DC from UNIOP system backplane, simplifying wiring

• Wide Temperature Range: Operate reliably in extreme industrial environments

• Plug-and-Play Integration: Seamless with UNIOP HMI/controllers for quick setup

• Compact Design: Space-saving for control cabinets with limited room

UNIOP ETT-VGA-0045 (5).png

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders

3. Typical Applications

• Industrial HMI: Extend UNIOP HMI to large external monitors for better data visibility

• Process Control: Display real-time process data, alarms, and trends in control rooms

• Manufacturing: Machine monitoring, CNC control visualization, production line dashboards

• Energy: Power plant monitoring, substation automation, renewable energy system displays

• Building Automation: HVAC, lighting, security system central monitoring

UNIOP ETT-VGA-0045 (3).png

4. Installation & Maintenance

Installation: Insert into UNIOP backplane slot; Connect VGA cable to external display; Power on system (5V backplane power auto-supplied); Set resolution via UNIOP HMI configuration software; Test video output and image stability.

Maintenance: Daily - Check VGA connection and display quality; Weekly - Inspect backplane slot contacts; Monthly - Clean VGA port (anti-static brush); Annual - Verify temperature tolerance and signal integrity.

Safety Notes: Use shielded VGA cables for EMI/RFI protection; Avoid hot-plugging under power; Follow ESD protocols (wrist strap, antistatic mat).

UNIOP ETT-VGA-0045 (1).png

Technical Document | ETT-VGA-0045 | UNIOP Industrial VGA Display Output Module
