Eaton XVS-440-10MPI-1-1AD HMI/PLC All-in-One--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Eaton XVS-440-10MPI-1-1AD 10.4" Infrared Touch HMI/PLC All-in-One (XVS400 Series)
XVS400 Series - Integrated HMI & PLC for Industrial Automation Monitoring & Control
1. Product Overview
The Eaton XVS-440-10MPI-1-1AD is a 10.4-inch HMI-PLC all-in-one from the XVS400 series, featuring an infrared touch screen and VGA (640×480) TFT color display, designed for intuitive monitoring and control in industrial automation systems. It supports 65536/256 adjustable colors, portrait display, and integrates Ethernet, RS232, PROFIBUS/MPI, and USB interfaces for seamless connectivity with PLCs, drives, and other industrial equipment. With a metal enclosure, IP65 front protection, and Windows CE OS (license required), it enables user-programmable PLC functions (via IEC 61131-3 compliant software) and flexible communication expansion with optional licenses, making it ideal for manufacturing, process control, and machinery automation applications requiring reliable HMI-PLC integration.
Key Specifications
• Model: XVS-440-10MPI-1-1AD | Brand: Eaton | Series: XVS400
• Type: 10.4" HMI-PLC All-in-One (User-Upgradable PLC Function)
• Display: 10.4" TFT Color, VGA (640×480), 65536/256 Adjustable Colors, Portrait Support
• Touch Technology: Infrared (IR) Touch, Durable for Industrial Environments
• Operating System: Windows CE (License Required)
• Built-in Interfaces: 1× Ethernet (10/100Base-TX), 1× RS232, 1× PROFIBUS/MPI, 2× USB Host, 1× USB Device
• PLC Compatibility: IEC 61131-3 Compliant (License: LIC-PLC-MXP-MEDIUM 140390)
• Power Supply: 24V DC (18-30V DC) | Power Dissipation: 25W
• Protection Class: Front IP65, Rear IP20 | Housing: Metal Enclosure & Front Plate
• Operating Temperature: 0°C to 50°C | Storage Temperature: -20°C to +60°C
• Approvals: UL508, cUL, CE (EN 61000-6-2/3) | Weight: 3.7 kg | Dimensions: 295×225×55mm
2. Core Features
• 10.4" IR Touch Screen: Durable, glove-compatible operation in harsh industrial settings
• HMI-PLC Integration: User-upgradable PLC function via IEC 61131-3 compliant software
• Multi-Interface Connectivity: Ethernet, RS232, PROFIBUS/MPI, USB for flexible system integration
• Adjustable Color Depth: 65536/256 colors for clear process visualization
• Portrait Display Support: Adapts to space-constrained control cabinets
• Robust Design: IP65 front protection, metal housing, wide temperature range (0°C to 50°C)
• License-Expandable Functions: PLC, communication interfaces configurable with optional licenses
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Manufacturing: Assembly Lines, Packaging Machines, Material Handling Systems
• Process Control: Chemical Plants, Water/Wastewater Treatment, Food & Beverage Processing
• Machinery Automation: Conveyor Systems, Printing Presses, Textile Machinery
• Building Automation: HVAC, Lighting, Access Control Systems
• Energy: Solar Inverter Control, UPS Monitoring, Generator Management
• General Industry: Any application requiring integrated HMI-PLC control and monitoring
4. Installation & Maintenance
Installation: Mount in control cabinet (VESA/Panel Cutout); Connect 24V DC power; Wire communication interfaces (Ethernet, RS232, PROFIBUS/MPI); Install Windows CE license; Configure HMI screens/PLC logic via Eaton software; Test connectivity with field devices.
Maintenance: Daily - Check screen responsiveness and system status; Weekly - Inspect power/communication connections; Monthly - Clean front panel (lint-free cloth, avoid chemicals); Annual - Verify IP65 sealing, update firmware if required.
Safety Notes: Power off during wiring; Use shielded cables for communication; Follow ESD protection (wrist strap, antistatic mat); Ensure proper grounding per Eaton guidelines.
Technical Document | XVS-440-10MPI-1-1AD | Eaton 10.4" Infrared Touch HMI/PLC All-in-One
