1. Product Overview
The ICS Triplex T8151B is an enhanced high-performance Triple Modular Redundancy (TMR) processor module for Rockwell AADvance safety instrumented systems (SIS), engineered for safety-critical industrial applications requiring ultra-high reliability, faster processing speeds, and expanded memory capacity (compared to the T9110). Built on a fault-tolerant TMR architecture with three identical PowerPC 750FX processing channels (800 MHz), it incorporates voting logic to ensure continuous operation even during single-channel failures, making it ideal for emergency shutdown (ESD), fire & gas (F&G), burner management (BMS), and distributed control (DCS) systems in oil & gas, petrochemical, nuclear power, and chemical industries. It features 1 GB ECC DRAM (4× larger than T9110), 128 MB Flash memory, dual 10/100/1000 Mbps Gigabit Ethernet ports, and dual RS-232/422 serial ports for seamless communication with AADvance I/O modules, HMI, and SCADA systems. With hot-swappable design, -25°C to +60°C operating temperature range, and compliance with IEC 61508 (SIL 3), IEC 61511, and IEEE 1686 standards, it delivers superior processing performance for complex control logic while maintaining the fault tolerance and safety integrity required for mission-critical industrial processes, minimizing downtime and ensuring personnel/equipment safety.
Key Specifications
• Model: T8151B | ICS Triplex Rockwell AADvance TMR Processor Module (Enhanced Performance)
• Architecture: Triple Modular Redundancy (TMR) with 3×PowerPC 750FX processing channels (800 MHz)
• Memory: 1 GB ECC DRAM (data processing); 128 MB Flash (firmware/configuration storage)
• Communication: 2×10/100/1000 Mbps Gigabit Ethernet (TCP/IP); 2×RS-232/422 serial ports (Modbus RTU/ASCII)
• I/O Expansion: Supports AADvance I/O modules (analog/digital/communication) via backplane bus; max 2048 I/O points
• Power Supply: 18–32 V DC (24 V DC nominal); Power Consumption: 12.0 W; Heat Dissipation: 40.9 BTU/hr
• Environmental: Operating: -25°C to +60°C (-13°F to +140°F); Storage: -40°C to +85°C; Humidity: 5–95% (non-condensing)
• Mechanical: 3U rack-mount (AADvance chassis); Dimensions: 195mm × 280mm × 100mm; Weight: 480 g (17 oz)
• Certifications: IEC 61508 (SIL 3), IEC 61511, IEEE 1686, CE, RoHS compliant
2. Core Features
• Enhanced TMR Performance: 800 MHz PowerPC 750FX processor (2× faster than T9110) for complex safety logic execution
• Expanded Memory: 1 GB ECC DRAM + 128 MB Flash to support large-scale control programs and high-volume data logging
• SIL 3 Compliance: Meets IEC 61508/IEC 61511 standards for safety-critical applications (ESD, F&G, BMS)
• Gigabit Ethernet Connectivity: Dual 10/100/1000 Mbps ports for high-speed data exchange with HMI/SCADA and I/O modules
• Hot-Swappable Module: Supports live replacement without system shutdown for minimal maintenance downtime
• Advanced Diagnostics: Real-time self-monitoring, fault logging, and online debugging tools for proactive maintenance
• High I/O Scalability: Supports up to 2048 I/O points for large-scale safety system deployments
• Wide Temperature Range: -25°C to +60°C operation for harsh industrial environments (e.g., offshore platforms, refineries)
