GE BK698CPA15B0 | VMIVME-7751 VME Single-Board Computer (SBC)
1.26GHz Pentium III VME64x Controller - Dual Ethernet, SVGA, Industrial - Grade Embedded Processing for Critical Automation
1. Product Overview
The GE BK698CPA15B0 is a VME64x - compliant single - board computer (SBC), part of the VMIVME - 7751 series, which is ideal for high - performance embedded control and real - time data processing in industrial automation, process control, and test & measurement applications. Powered by a 1.26GHz Intel Pentium III processor with 256KB L2 cache, it offers robust computing power to handle complex control algorithms and high - speed data acquisition. It features dual 10/100Base - TX Ethernet ports, an AGP SVGA controller, RS - 232/422 serial ports, and optional PCI Ultra160 SCSI, ensuring seamless connectivity with industrial networks and peripherals. With an operating temperature range of - 40°C to +85°C, compliance with CE, UL, and VME64x standards, and a rugged design, it can reliably operate in harsh industrial environments, making it suitable for power generation, oil & gas, petrochemical, and aerospace test systems, providing stable embedded processing for critical control tasks.
Key Specifications
• Model: BK698CPA15B0 (VMIVME - 7751 Series VME Single - Board Computer)
• Processor: 1.26GHz Intel Pentium III, 256KB Full - Speed L2 Cache
• Memory: Up to 512MB PC133 SDRAM (SODIMM), 4MB AGP SVGA Video Cache
• Bus: VME64x (Backplane - Compatible with VMEbus)
• Communication: Dual 10/100Base - TX Ethernet; RS - 232/422 Serial Ports; Optional PCI Ultra160 SCSI
• I/O Expansion: VME Backplane for I/O Modules; PCI Expansion (Optional)
• Power: +5V, +12V, -12V (from VME Backplane); Typical Power Consumption: 25W
• Operating Temperature: -40°C to +85°C (-40°F to +185°F); Storage: -55°C to +125°C (-67°F to +257°F)
• Dimensions: 160mm × 233mm (6.3" × 9.17") (3U VME Form Factor); Weight: ~4.06kg
• Certifications: CE, UL 508, IEC 61010 - 1, RoHS Compliant
2. Core Features
• High - Performance Processing: 1.26GHz Pentium III handles complex control, real - time data acquisition, and multitasking.
• Flexible Expansion: VME64x backplane supports diverse I/O modules for custom automation system building.
• Dual Network Connectivity: Redundant Ethernet ensures reliable communication for industrial networks and remote monitoring.
• Industrial - Grade Durability: Operates at - 40°C to +85°C, suitable for extreme - environment embedded applications.
• Graphics Support: AGP SVGA controller enables HMI interfaces and local monitoring.
• Easy Integration: Works with VME - based I/O, sensors, and PLCs; Supports Modbus, Profinet, and Custom Protocols.
• Long - Term Availability: Legacy Support for Critical Industrial Systems; Compatible with Classic VME Infrastructure.
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
Sales Manager: KI MI
WeChat: 18059884790
Global Inventory: 121 shared inventories worldwide,
enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan,
South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia,
Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty,
and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments
if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders.
3. Typical Applications
• Power Generation: Substation automation data acquisition, turbine control, and grid - connected monitoring systems.
• Oil & Gas: Refinery process control, pipeline monitoring, and compressor vibration data processing.
• Petrochemical: Plant safety interlock systems, reactor temperature/ pressure control, and batch processing.
• Aerospace: Avionics test platforms, flight data acquisition, and embedded control for ground support equipment.
• Industrial Automation: 3U VME - based PLC/ DCS, high - speed machine vision, and real - time motion control.
4. Installation & Maintenance
Installation: Install in 3U VME Chassis; Connect power via VME backplane; Wire Ethernet/ serial to network/ devices; Set VME address switches for backplane communication.
Configuration: Load OS (Linux, VxWorks, Windows Embedded) via flash/ network; Configure Ethernet (DHCP/ Static IP) and serial ports; Set VME interrupts for I/O modules.
Maintenance: Monthly: Check power/ temperature; Verify network connectivity and LED status. Quarterly: Inspect backplane connectors and clean vents; Test redundant Ethernet failover. Annual: Replace CMOS battery; Update firmware/ OS patches; Perform memory/ I/O diagnostic tests.
Fault Diagnosis: No power: Check backplane power and module seating. No network: Verify IP settings and cable connections. VME I/O failure: Check address switches and interrupt settings; Reseat I/O modules.
