GE DL-1200 RTU High-Performance Industrial Remote Terminal Unit (Proficy Series)

Reliable SCADA Integration for Remote Monitoring & Distributed Control in Harsh Environments

1. Product Overview

The GE DL-1200 RTU is an industrial-grade Remote Terminal Unit (RTU) from GE Digital's Proficy series, engineered for data acquisition, real-time control, and protocol conversion in critical infrastructure sectors like power, oil & gas, water/wastewater, and renewable energy. It features a dual-core ARM Cortex-A9 1.2GHz processor with 4GB DDR4 RAM and 4GB eMMC storage, delivering sub-10ms response times for high-speed monitoring and distributed control. The modular design supports scalable I/O (up to 32 AI, 64 DI, 16 AO, 16 DO) and multiple communication interfaces, including dual Ethernet (10/100Base-TX), RS232/RS485 serial ports, and optional GPRS/4G cellular modules. It supports over 20 industrial protocols (Modbus RTU/TCP, DNP3, IEC 60870-5-101/104, IEC 61850, MQTT) and integrates a protocol conversion engine for seamless SCADA/DCS/IIoT connectivity. With dual-redundant 24VDC power inputs, IP65 front/IP20 rear protection, and an operating temperature range of -40°C to +75°C, it ensures 24/7 reliability in extreme industrial environments. UL 61010-1 and IEC 61131-2 certifications confirm compliance with global safety standards for mission-critical applications.

GE DL-1200 RTU (2).png

Key Specifications

• Manufacturer: GE Digital (Proficy Series Industrial RTU)

• Model: DL-1200 RTU (Remote Terminal Unit)

• Processor: Dual-core ARM Cortex-A9, 1.2GHz

• Memory: 4GB DDR4 RAM, 4GB eMMC Flash Storage

• I/O Capacity: Up to 32 AI (16-bit, 4-20mA/0-10V), 64 DI (dry/wet contacts), 16 AO (4-20mA), 16 DO (relay/transistor)

• Communication Interfaces: 2×Ethernet (RJ45), 2×RS485 (DB9), 1×RS232 (DB9), Optional GPRS/4G Cellular

• Supported Protocols: Modbus RTU/TCP, DNP3, IEC 60870-5-101/104, IEC 61850, MQTT, CDT

• Power Supply: Dual-redundant 24VDC (-15% to +20%), 15W Max Power Consumption

• Protection Rating: IP65 Front (IEC 60529), IP20 Rear

• Operating Temperature: -40°C to +75°C, Storage: -40°C to +85°C

• Dimensions (W×H×D): 300mm × 200mm × 100mm, Weight: ~2.5kg

• Certifications: UL 61010-1, IEC 61131-2, CE, ATEX Zone 2

GE DL-1200 RTU (5).png

2. Core Features

• High-Speed Processing: Dual-core ARM 1.2GHz processor with sub-10ms response for real-time control and data logging.

• Multi-Protocol Support: 20+ industrial protocols (Modbus, DNP3, IEC 60870, IEC 61850, MQTT) for SCADA/DCS/IIoT integration.

• Protocol Conversion Engine: Maps legacy protocols to OPC UA/MQTT for seamless IIoT connectivity without system upgrades.

• Scalable I/O: Modular design supports up to 32 AI, 64 DI, 16 AO, 16 DO for flexible field device integration.

• Redundant Power & Communication: Dual 24VDC inputs and dual Ethernet ports ensure continuous operation during outages.

• Rugged Design: IP65 front protection, -40°C to +75°C operating range, and surge immunity for extreme environments.

• Predictive Diagnostics: Built-in self-monitoring for power, I/O, and communication faults with remote alerting via email/SMS.

• Secure Connectivity: Supports TLS 1.3, VPN, and role-based access control (RBAC) for data integrity and cyber protection.

3. Typical Applications

• Power Utilities: Substation automation, distribution grid monitoring, and smart meter data aggregation (DNP3/IEC 61850 compliant).

• Oil & Gas: Pipeline leak detection, wellhead monitoring, and tank farm inventory management with cellular/GPRS redundancy.

• Water/Wastewater: Pump station control, chemical dosing automation, and treatment process visualization (Modbus/IEC 60870-5-104).

• Renewable Energy: Wind farm turbine monitoring, solar inverter data logging, and grid integration with MQTT for IIoT analytics.

• Industrial Automation: Remote PLC control, factory energy management, and legacy DCS migration to cloud-based SCADA.

• Transportation: Railway signaling system monitoring, pipeline valve control, and remote asset tracking with GPS integration.

GE DL-1200 RTU (3).png

4. Installation & Maintenance

Installation: Mount on EN 60715 DIN rail; connect dual 24VDC power inputs to redundant terminals. Wire AI/DI/AO/DO to I/O modules (4-20mA for AI, dry contacts for DI). Connect Ethernet to SCADA network and RS485 to Modbus RTU devices. Verify PWR/COM LEDs are active; optional 4G antenna for cellular backup.

Configuration: Use GE Proficy Machine Edition (PME) software to configure I/O mapping, protocol stacks (DNP3, IEC 60870), and data logging intervals. Set up MQTT broker connection for IIoT cloud integration; enable TLS 1.3 for secure communication.

Maintenance: Monthly checks: LED status, terminal tightness, and power supply voltage. Annual: Test insulation resistance (>100 MΩ) and verify communication latency with SCADA master. Clean air vents quarterly to prevent dust buildup; replace backup battery every 2 years.

Fault Diagnosis: Red PWR LED = power supply fault; check dual 24VDC inputs. Flashing COM LED = communication error; verify Ethernet/RS485 wiring and protocol settings. I/O fault = check module connections and sensor calibration.

GE DL-1200 RTU (1).png
