GE IC695CPU315-BB | PACSystems RX3i 1.0 GHz CPU Module
1.0 GHz Celeron-M CPU, 20 MB User Memory, 2048 I/O Points, Dual Serial + Ethernet for Industrial Automation & Process Control
1. Product Overview
The GE IC695CPU315-BB is a high-performance Central Processing Unit (CPU) module for PACSystems RX3i, powered by a 1.0 GHz Intel Celeron-M processor, 20 MB user memory (program/data) and 20 MB NVRAM (non-volatile data storage), delivering Boolean logic execution speed of 0.017 ms/K and supporting up to 2048 discrete I/O points (or equivalent mixed I/O) for real-time industrial control. It integrates 1×10/100 Mbps Ethernet (Modbus TCP/IP, SRTP), 1×RS-232 (COM1), and 1×RS-232/485 (COM2, Modbus RTU/SNP) ports, plus a 128 MB CompactFlash slot for program backup/restore. The module supports 512 program blocks (128 KB max each), dual PCI backplanes, and firmware upgrades, with redundant power support, operating temperature range of 0°C to +60°C, and compliance with IEC 61131-3, CE, UL standards, ideal for process control, manufacturing automation, and energy management systems requiring reliable, scalable, and easy-to-integrate PAC control.
Key Specifications
• Model: IC695CPU315-BB | PACSystems RX3i 1.0 GHz CPU Module (Series BB)
• Processor: Intel Celeron-M 1.0 GHz; Boolean Logic: 0.017 ms/K
• Memory: 20 MB User RAM (program/data); 20 MB NVRAM (non-volatile); 128 MB CompactFlash slot
• I/O Capacity: Max 2048 discrete I/O points (or equivalent mixed I/O); 512 program blocks (128 KB max each)
• Communication: 1×10/100 Mbps Ethernet (Modbus TCP/IP, SRTP); 1×RS-232 (COM1); 1×RS-232/485 (COM2, Modbus RTU, SNP)
• Expansion: Up to 8 I/O racks via RX3i PCI backplane; dual backplane buses (I/O + intelligent options)
• Power: 5V DC (1.2A), 3.3V DC (1.0A); redundant power input support
• Environmental: 0°C to +60°C (+32°F to +140°F); Storage: -40°C to +85°C (-40°F to +185°F); Humidity: 5% to 95% (Non-condensing)
• Dimensions: 71mm × 135mm × 135mm (2.8" × 5.3" × 5.3"); Net Weight: 0.79 kg (1.75 lbs)
• Certifications: IEC 61131-3, CE, UL, RoHS
2. Core Features
• High-Speed Processing: 1.0 GHz Celeron-M enables fast logic execution (0.017 ms/K Boolean) for real-time control
• Non-Volatile Storage: 20 MB NVRAM + CF slot for program/data backup without battery dependency
• Multi-Protocol Connectivity: Ethernet (Modbus TCP/IP, SRTP) + dual serial (RS-232/485, Modbus RTU, SNP) for seamless system integration
• Scalable I/O: Max 2048 discrete I/O points; supports 4/8/16-slot RX3i I/O bases and all discrete/analog modules
• Redundant Power: Dual power inputs for fault tolerance in critical control networks
• IEC 61131-3 Compliance: Supports Ladder Logic, Structured Text, Function Block Diagram programming
• Firmware Upgradeable: In-system firmware updates for feature expansion and security patches
• Advanced Diagnostics: LED indicators for status (Power, Run/Stop, Fault, Communication) and error code display
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
Sales Manager: KI MI
WeChat: 18059884790
Global Inventory: 121 shared inventories worldwide, enabling direct procurement
from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea,
United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands,
Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty,
and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments
if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
