DANAHER S21260-SRS Compact SynqNet Brushless Servo Driv--KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

DANAHER S21260-SRS Compact SynqNet Brushless Servo Drive (S200 Series)

High-Precision Motion Control for Industrial Automation & Precision Machinery

1. Product Overview

The DANAHER S21260-SRS is a fully digital, compact brushless servo drive from the S200 series (now Kollmorgen), designed for high-precision motion control in industrial automation, semiconductor manufacturing, packaging machinery, and medical equipment. It delivers precise position, speed, and torque control with a 100 MHz DSP, supporting 12 ARMS continuous output current (40°C) and 18 ARMS peak current (3s), paired with a 5 kHz current loop and 800 Hz speed loop bandwidth for ultra-fast dynamic response. The drive integrates a pre-installed SynqNet (RJ45) communication module for real-time networked motion control, and is optimized for SFD (Smart Feedback Device) motors with 24-bit high-resolution feedback, enabling plug-and-play setup and simplified tuning. Its compact form factor (54.8×175×132mm, 1.33kg) and DIN-rail mounting support seamless integration into space-constrained industrial cabinets, while a wide operating temperature range (-25°C to +70°C) and comprehensive protection functions (overcurrent, overvoltage, overheating, short circuit) ensure reliable operation in harsh industrial environments.

DANAHER S21260-SRS (5).png

Key Specifications

• Manufacturer: Danaher Motion (now Kollmorgen)

• Model: S21260-SRS (S200 Series Compact Brushless Servo Drive)

• Input Voltage: 120/240 VAC (1/3 phase), 47-63 Hz, 0-264 VAC (max)

• Output Current: 12 ARMS continuous (40°C), 8 ARMS (50°C), 18 ARMS peak (3s)

• Control Loops: 5 kHz current loop, 800 Hz speed loop bandwidth

• Feedback: SFD (Smart Feedback Device), 24-bit resolution

• Communication: Pre-installed SynqNet (RJ45), supports Modbus/CANopen/EnDat

• Control Modes: Position, Speed, Torque (configurable via software)

• Dimensions: 54.8mm × 175mm × 132mm, Weight: 1.33 kg

• Operating Conditions: -25°C to +70°C, 5%–95% RH (non-condensing)

• Protection: Overcurrent, Overvoltage, Overheating, Short Circuit, Phase Loss

• Certifications: CE, UL, IEC 61800-5-1 compliant

DANAHER S21260-SRS (2).png

2. Core Features

• Ultra-Fast Response: 5 kHz current loop + 800 Hz speed loop for precise motion and rapid acceleration/deceleration.

• SynqNet Integration: Pre-installed RJ45 module enables real-time networked motion control with sub-microsecond synchronization.

• SFD Motor Optimization: 24-bit feedback and electronic motor nameplate for plug-and-play setup and simplified tuning.

• Compact Design: 54.8×175×132mm form factor saves 40% cabinet space vs. traditional drives.

• Multi-Mode Control: Switchable position/speed/torque modes via software for flexible application adaptation.

• Comprehensive Protection: Real-time monitoring prevents damage from electrical faults and thermal overload.

• Wide Voltage Range: 120/240 VAC (1/3 phase) compatibility for global industrial power grids.

DANAHER S21260-SRS (1).png

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement
from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea,
United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands,
Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty,
and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments
if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders.

3. Typical Applications

• Semiconductor Manufacturing: Wafer handling robots, lithography stage positioning, and die attach equipment.

• Packaging Machinery: High-speed pick-and-place systems, labelers, and form-fill-seal machines requiring precise registration.

• Medical Equipment: Diagnostic imaging (CT/MRI) motion control, surgical robotics, and automated lab sample handlers.

• Industrial Automation: CNC machine tool axes, robotic arm joints, and material handling gantries.

• Electronics Assembly: PCB placement machines, component insertion systems, and 3D printing motion control.

• Test & Measurement: Automated test equipment (ATE) with high dynamic response and position accuracy requirements.

DANAHER S21260-SRS (3).png

4. Installation & Maintenance

Installation: Mount on EN 60715 DIN rail; connect 120/240 VAC power (1/3 phase) to L1/L2/L3 terminals. Wire motor phases to U/V/W and SFD feedback to the dedicated port. Connect SynqNet RJ45 for network communication; verify PWR/COM LEDs are active.

Configuration: Use Kollmorgen WorkBench software to set control mode (position/speed/torque), tune PID parameters, and configure SynqNet node settings. Load motor parameters via SFD auto-detection for plug-and-play operation.

Maintenance: Monthly checks: LED status, terminal tightness, and heatsink temperature. Annual: Test insulation resistance (>100 MΩ) and verify current loop response with a scope. Clean air vents quarterly to prevent dust buildup.

Fault Diagnosis: Red PWR LED = power supply fault; check voltage and wiring. Flashing COM LED = SynqNet communication error; verify network connection and node ID. Overcurrent fault = check motor phase short or load overload.

Technical Document | DANAHER S21260-SRS | Compact SynqNet Brushless Servo Drive
