Motorola MVME6100 6U VME Single-Board Computer (SBC)--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Motorola MVME6100 6U VME Single-Board Computer (SBC)
High-Performance VMEbus Embedded Computing for Industrial, Military & Aerospace Control Systems
1. Product Overview
The Motorola MVME6100 is a 6U VME single-board computer (SBC) with MPC7457 PowerPC processor (1.267 GHz) and Tundra Tsi148 VME interface chip, pioneering the 2eSST VMEbus protocol (320 MB/s transfer rate). It integrates dual Gigabit Ethernet, DDR ECC memory (up to 2 GB), 128 MB flash, and two PMC-X expansion slots, serving as a core embedded computing platform for industrial control, military, and aerospace applications. With AltiVec coprocessor for parallel data processing, it excels in data-intensive tasks, supporting VxWorks/Linux and seamless integration with legacy VME systems, ensuring reliable performance in harsh environments (-40°C to +85°C).
2. Key Technical Specifications
• Brand & Model: Motorola MVME6100 (6U VME Single-Board Computer)
• Processor: MPC7457 PowerPC (1.267 GHz) with 128-bit AltiVec Coprocessor
• Memory: Up to 2 GB DDR ECC SDRAM (Expandable), 128 MB Flash (On-Board)
• Storage: CompactFlash, SATA Interface (Optional 2.5" HDD/SSD)
• VME Interface: Tundra Tsi148 ASIC, 2eSST Protocol (320 MB/s), A16/A24/A32/A64 Addressing
• Networking: Dual Gigabit Ethernet (10/100/1000BASE-T)
• Serial: 2x RS-232/422/485 (Configurable), 1x RS-232 Console
• USB: 2x USB 2.0 Ports
• Expansion: 2x PMC-X Slots (33/66/100 MHz, 32/64-bit PCI)
• Power: VME Backplane (+5V, +12V); On-Board Regulation (+3.3V, +2.5V, +1.8V)
• Power Consumption: 25 W (Typical)
• Form Factor: 6U VME (233.4 mm × 160 mm)
• Operating Temperature: -40°C to +85°C
• Storage Temperature: -55°C to +125°C
• Certifications: MIL-STD-810G (Shock/Vibration), MIL-STD-461 (EMI/EMC)
3. Core Features
• 2eSST VMEbus: 320 MB/s Transfer Rate, Tundra Tsi148 ASIC for High-Speed Data Exchange
• AltiVec Coprocessor: 128-bit Parallel Processing for Data-Intensive Industrial/Aerospace Apps
• Dual Gigabit Ethernet: Redundant High-Speed Networking for Critical Control Systems
• PMC-X Expansion: 2 Slots for I/O, Communication, or Specialized Function Modules
• ECC Memory: DDR ECC SDRAM for Data Integrity in High-Reliability Environments
• Multi-OS Support: VxWorks, Linux, and Other Real-Time Operating Systems
• Rugged Design: -40°C to +85°C Operation, MIL-STD Compliance for Harsh Conditions
• Legacy Compatibility: Works with VME64x Systems, A16/A24/A32/A64 Addressing Modes
4. Typical Applications
• Industrial Automation: Distributed Control Systems (DCS), PLC, and Robotics Motion Control
• Military: Avionics Control, Radar Signal Processing, and Embedded Weapon Systems
• Aerospace: Satellite Ground Control, Flight Simulation, and Aircraft Engine Monitoring
• Energy: Power Grid Management, Turbine Control, and Nuclear Plant Safety Systems
• Transportation: Railway Signaling, Traffic Management, and Shipboard Embedded Computing
• Medical: Diagnostic Imaging Equipment and Laboratory Automation (High-Reliability Computing)
5. Installation & Maintenance
Installation Steps
• Mounting: Install into 6U VME Chassis (Align with P1/P2 Connectors; Secure with Thumbscrews)
• Power: Connect VME Backplane Power (+5V, +12V); Verify On-Board Voltage Regulation
• Configuration: Set VME Geographical Address (S3), Configure Ethernet/Serial via OS or JTAG
• Testing: Validate VMEbus Communication, Memory Integrity, and Ethernet Connectivity
Maintenance Tips
• Daily: Check LEDs for Power, VMEbus Activity, and Ethernet Link Status
• Weekly: Inspect VME/Power Connectors for Loose/Damaged Cables; Clean Air Vents (If Chassis-Mounted)
• Monthly: Run Memory Tests (ECC Validation) and Verify Storage Media (Flash/CompactFlash) Integrity
• Quarterly: Test PMC-X Modules for Functionality and Update OS/Firmware (If Required)
• Annual: Inspect for Component Degradation; Replace Flash/Storage if End-of-Life
