Product Description

Emerson/Motorola MVME55006E-0163 VMEbus Single Board Computer

High - Performance Embedded Computing for Industrial Automation & Aerospace

1. Product Overview

The Emerson/Motorola MVME55006E-0163 is a high - performance VMEbus single - board computer (SBC) in the MVME5500 series, designed for high - reliability embedded computing and real - time control applications. It is equipped with a 1 GHz PowerPC MPC7457 processor with an AltiVec coprocessor, which provides powerful computing capabilities for data - intensive tasks. The board integrates rich I/O interfaces and expansion buses, supports dual independent 64 - bit PCI buses and PMC expansion sites, and is compatible with the MVME51xx family. It is widely used in industrial automation, aerospace, national defense, medical imaging and other fields, and can stably operate in harsh industrial environments, providing a reliable embedded computing platform for critical systems.

MVME55006E-0163 -2(1).png

2. Key Technical Specifications

• Brand & Model: Emerson/Motorola MVME55006E-0163

• Product Type: VMEbus Single Board Computer (SBC)

• Processor: 1 GHz PowerPC MPC7457 with AltiVec Coprocessor

• Cache: 512 KB On - Chip L2 Cache, 2 MB L3 Cache

• Memory: 512 MB 133 MHz SDRAM (ECC), Supports Up to 1 GB via Memory Mezzanine

• Storage: 32 MB + 8 MB Soldered Flash Memory

• System Controller: Marvell, 133 MHz Host & SDRAM Memory Buses

• Buses: VMEbus (64 - bit/32 - bit, Up to 160 MB/s), Dual Independent 64 - bit PCI (66 MHz)

• Network Interfaces: 1 x Gigabit Ethernet, 1 x 10/100BaseTX Ethernet

• Serial Ports: 2 x Asynchronous Serial Ports (RS - 232)

• Expansion: 2 x PMC Sites, Supports Up to 4 Additional PMCs via Expansion Connector

• I/O Compatibility: MVME51xx Family

• Operating Temperature: 0°C to +55°C (32°F to +131°F)

• Dimensions: 230 × 167 × 64 mm (9.06 × 6.57 × 2.52 in)

• Weight: 0.43 kg (0.95 lbs)

• Protection Class: IP20

MVME55006E-0163 -1(1).jpg

3. Core Features

• High - Performance Computing: 1 GHz MPC7457 Processor with AltiVec Coprocessor for Complex Data Processing.

• ECC Memory: 512 MB ECC SDRAM Ensures Data Integrity in Critical Applications.

• Flexible Expansion: Dual 64 - bit PCI Buses & PMC Sites for Various I/O Modules.

• Rich Network Connectivity: Gigabit + 10/100BaseTX Ethernet for Fast Data Transmission.

• Industrial - Grade Reliability: Designed for Harsh Environments with Anti - Vibration & Shock Capability.

• Backward Compatibility: I/O Compatible with MVME51xx Family for Easy System Upgrade.

• Compact Design: Single VME Slot Even with Full PMC Configuration.

• Real - Time OS Support: Compatible with VxWorks, Linux, and Other RTOS.

MVME55006E-0163 -5(1).png

4. Typical Applications

• Industrial Automation: Process Control, Data Acquisition, and Real - Time Monitoring Systems.

• Aerospace: Avionics, Flight Control, and Navigation Systems.

• Defense: Military Embedded Computing, Weapon Control, and Communication Systems.

• Medical Imaging: High - Speed Image Processing and Diagnostic Equipment Control.

• Transportation: Railway Signaling, Traffic Control, and Vehicle Embedded Systems.

• Energy: Power Grid Monitoring, Oil & Gas Exploration Data Processing.

MVME55006E-0163 -4(1).png

5. Installation & Maintenance

• Mounting: Installed in a Standard VMEbus Backplane Slot (Single Slot Occupancy).

• Wiring: Connect Ethernet, Serial Ports, and PMC Expansion Modules as Needed.

• Configuration: Set Up via JTAG or Network for OS Installation and Parameter Tuning.

• Diagnostics: Use Built - in Debug Interfaces and RTOS Tools for System Troubleshooting.

• Maintenance: Regularly Inspect for Dust Accumulation; Check Connectors for Looseness.

• Safety Guidelines: Power Off Before Installation/Maintenance; Follow ESD Protection Rules.

MVME55006E-0163 -3(1).png

Technical Document | Emerson/Motorola MVME55006E-0163 | VMEbus Single Board Computer | Embedded Computing
