GE Multilin D20 EME 10BASE-T Communication Module--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
GE Multilin D20 EME 10BASE-T Communication Module
Ethernet Communication Interface for D20 Digital Protection & Control Systems
1. Product Overview
The GE Multilin D20 EME 10BASE-T is a dedicated Ethernet communication module for the GE Multilin D20 series digital protection and control systems, widely used in power generation, transmission, and distribution networks. It provides a 10BASE-T twisted-pair Ethernet interface to enable data exchange between D20 relays, RTUs (Remote Terminal Units), SCADA systems, and engineering workstations. With support for standard industrial protocols, built-in diagnostic functions, and rugged design, it ensures reliable remote monitoring, configuration, and fault reporting for substation automation, generator protection, and feeder control applications, enhancing system visibility and operational efficiency.
2. Key Technical Specifications
• Product Type: 10BASE-T Ethernet Communication Module
• Brand & Model: GE Multilin D20 EME 10BASE-T (D20 Series)
• System Compatibility: GE Multilin D20 Digital Protection & Control Systems
• Communication Interface: 1× 10BASE-T RJ45 Port (Twisted-Pair Ethernet)
• Supported Protocols: DNP3.0, MODBUS TCP, GE SRTP (Station Remote Terminal Protocol)
• Data Transfer Rate: 10 Mbps (Half/Full Duplex Configurable)
• Network Topology: Star, Bus (with External Hubs/Switches)
• Supply Voltage: Powered by D20 Chassis Backplane (5 VDC / 24 VDC)
• Power Consumption: 3 W Max.
• Operating Temperature: -40°C to +70°C (-40°F to +158°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Humidity: 5% - 95% RH (Non-Condensing)
• Protection Class: IP20 (Chassis Mounted)
• Dimensions (L×W×H): 127 × 89 × 38 mm (5.0 × 3.5 × 1.5 in)
• Weight: 0.25 kg (0.55 lbs)
• Certifications: CE, UL 1012, IEC 61850-3 (Substation Automation Compliance)
3. Core Features
• 10BASE-T Ethernet Interface: Enables Reliable 10 Mbps Data Communication for Substation Automation.
• Multi-Protocol Support: DNP3.0, MODBUS TCP, SRTP for Seamless Integration with SCADA/RTU Systems.
• Backplane Powered: No External Power Required, Simplifying Installation and Reducing Wiring.
• Diagnostic Functions: Built-In Self-Test (BIST) and Network Status Monitoring with LED Indicators.
• Rugged Design: Wide Temperature Range (-40°C to +70°C) for Harsh Substation Environments.
• Easy Configuration: Configurable via D20 Local Interface or Remote Engineering Workstation.
• Hot-Swappable: Supports Online Replacement Without Disrupting D20 System Operation.
• Network Isolation: Galvanic Isolation Between Ethernet Port and Chassis Backplane for Noise Immunity.
4. Typical Applications
• Substation Automation: Data Exchange Between D20 Relays and SCADA Systems for Grid Monitoring.
• Generator Protection: Remote Configuration & Fault Reporting for Turbine/Generator Protection Relays.
• Feeder Control: Real-Time Monitoring of Distribution Feeders & Circuit Breaker Status.
• Transmission Line Protection: Communication Between Line Relays and Central Control Centers.
• Industrial Power Systems: Integration with Plant DCS for Unified Power Management.
• Renewable Energy: Solar/Wind Farm Substation Control & Grid Connection Monitoring.
5. Installation & Maintenance
• Mounting: Plug-in Installation to D20 Chassis Dedicated Communication Slot (No Tools Required).
• Wiring: Connect 10BASE-T Ethernet Cable to RJ45 Port; Use Shielded Twisted-Pair (STP) Cable for Noise Reduction.
• Configuration: Set IP Address, Protocol Parameters via D20 Local HMI or Remote Engineering Software.
• Hot-Swap: Replace Module Online (Chassis Powered) Without Interrupting Protection Functions.
• Maintenance: Check LED Indicators (Link/Activity, Fault) for Network Status; Clean RJ45 Port Periodically.
• Troubleshooting: Verify Network Connection with Ping Command; Check Protocol Configuration for SCADA Integration Issues.
• Safety Guidelines: Disconnect Chassis Power Before Initial Installation; Use ESD Protection for Module Handling.
Technical Document | GE Multilin D20 EME 10BASE-T | 10BASE-T Communication Module | Substation Automation Systems
