KONGSBERG AUE-1108 8100183 dPSC Dual Process Segment Controller
Distributed Control & Redundant Communication for Marine Automation Systems
1. Product Overview
The KONGSBERG AUE-1108 8100183 (dPSC 4605, Part No. 6200379 Rev. B1) is a dual process segment controller (dPSC) designed for KONGSBERG Maritime automation systems, serving as a core module for distributed control and redundant communication in marine vessels. It integrates two independent process segments to enable fault-tolerant operation, supporting real-time data exchange between field devices and the central control system. With hot-swappable capability and built-in diagnostics, it ensures continuous operation of critical ship systems such as propulsion, power management, and cargo handling, suitable for offshore platforms, merchant ships, and naval vessels.
2. Key Technical Specifications
• Product Type: Dual Process Segment Controller (dPSC)
• Brand & Model: KONGSBERG AUE-1108, 8100183, dPSC 4605 (Part No. 6200379 Rev. B1)
• System Compatibility: KONGSBERG NORCONTROL Maritime Automation System
• Process Segments: 2 Independent Segments (Redundant Configuration)
• Communication Protocol: CANopen, Ethernet/IP (Optional), MODBUS TCP (Optional)
• Input/Output Interfaces: 8 Digital Inputs, 8 Digital Outputs, 4 Analog Inputs (4-20 mA)
• Supply Voltage: 24 VDC (Nominal, ±15% Tolerance)
• Power Consumption: 15 W Max. (24 VDC)
• Operating Temperature: -25°C to +60°C (-13°F to +140°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Protection Class: IP20 (Module Chassis Mount)
• Dimensions (H×W×D): 100 × 160 × 220 mm (3.94 × 6.30 × 8.66 in)
• Weight: 1.78 kg (3.92 lbs)
• Hot-Swap Capability: Supported (No System Interruption with Redundant Segment)
• Certifications: DNV, ABS, Lloyd's Register, CE
3. Core Features
• Dual Process Segments: Two Independent Segments for Fault-Tolerant Operation (No Single Point of Failure).
• Redundant Communication: Supports CANopen, Ethernet/IP, MODBUS TCP for Real-Time Data Exchange.
• Hot-Swap Function: Replace Module Without System Shutdown (Redundant Segment Active).
• Built-In Diagnostics: Self-Monitoring for Fault Detection (Segment Status, Power, Communication).
• I/O Expansion: Compatible with KONGSBERG Remote I/O Modules (RDi-32, RAo-8, etc.).
• Marine-Grade Design: Operates in Harsh Environments (Shock, Vibration, Salt Spray Resistance).
• Configuration Software: KONGSBERG NORCONTROL Configurator for Segment Setup & I/O Mapping.
• Alarm Handling: Local LED Indicators & Central System Alerts for Critical Faults.
4. Typical Applications
• Marine Propulsion: Main Engine Control & Thruster Management (Dynamic Positioning Systems).
• Power Management: Shipboard Generator Control & Load Distribution (PMS Integration).
• Cargo Handling: Container Ship Cargo Control & Tanker Loading/Unloading Systems.
• Offshore Platforms: Drilling Equipment Control & Safety Shutdown Systems (ESD).
• Naval Vessels: Combat System Integration & Auxiliary Equipment Control.
• Merchant Ships: Ballast Water Management & HVAC Control (Energy Efficiency Optimization).
5. Installation & Maintenance
• Mounting: DIN Rail Mount (35 mm) in Control Cabinet; Ensure Proper Ventilation.
• Wiring: 24 VDC Power via Screw Terminals (2.5 mm² Max. Cable, Torque 0.8 Nm).
• Redundancy Setup: Connect Both Process Segments to Redundant Network Switches.
• Hot-Swap: Replace Module While Redundant Segment is Active (No System Interruption).
• Maintenance: Check LED Indicators for Segment Status; Update Firmware via USB Port Annually.
• Troubleshooting: Use KONGSBERG Configurator to Monitor Segment Communication & I/O Status.
• Safety Guidelines: Isolate Power Before Installation; Use ESD Protection for Module Handling.
Technical Document | KONGSBERG AUE-1108 | 8100183 | dPSC Dual Process Segment Controller | Marine Automation Systems
