Basler acA2040-180kc (A402KC) Industrial Area Scan Camera--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Basler acA2040-180kc (A402KC) Industrial Area Scan Camera
4 MP Global Shutter CMOS Camera with Camera Link Interface for High-Speed Machine Vision Applications
1. Product Overview
The Basler acA2040-180kc (Model: A402KC) is a high-performance 4-megapixel industrial area scan camera equipped with a 1" global shutter CMOS sensor (ams CMV4000). It features a Camera Link interface, 180 fps frame rate, and 10/12-bit pixel depth, delivering high-speed, high-resolution image capture for industrial machine vision, automated inspection, and quality control. With industrial-grade reliability, it excels in harsh manufacturing environments, enabling precise defect detection, part identification, and process monitoring in automotive, electronics, and semiconductor industries.
2. Key Technical Specifications
• Product Type: 4 MP Industrial Area Scan Camera (Color/Monochrome Option)
• Brand: Basler (Model: acA2040-180kc; Alternate Model: A402KC)
• Sensor: ams CMV4000 CMOS, 1" Global Shutter (11.3 mm × 11.3 mm Chip Size)
• Resolution: 2046 × 2046 Pixels (4 Megapixels)
• Pixel Size: 5.5 µm × 5.5 µm
• Frame Rate: 180 fps (Max, Full Resolution)
• Interface: Camera Link (Base/Medium/Full Configurable, 32.5/48/65/82 MHz Clock)
• Pixel Bit Depth: 10 Bits, 12 Bits (Configurable)
• Exposure Control: Trigger Width, Timed Exposure, Free-Run, Hardware/Software Trigger
• Quantum Efficiency (Typical): 62.1% (Color), 65% (Monochrome)
• Dynamic Range (Typical): 58.7 dB
• Power Supply: 12 VDC (2.5 A Max Current)
• Operating Temperature: -10°C to +60°C
• Storage Temperature: -40°C to +85°C
• Dimensions: 60 mm × 60 mm × 30 mm (2.36" × 2.36" × 1.18")
• Weight: 0.2 kg (0.44 lbs)
• Protection: IP30, ESD Protection (±8 kV Contact, ±15 kV Air Discharge)
• Certification: CE, UL, RoHS, REACH
3. Core Features
• Global Shutter: Eliminates motion blur for fast-moving object capture.
• High Frame Rate: 180 fps enables real-time inspection of high-speed production lines.
• Camera Link Flexibility: Supports Base/Medium/Full configurations for diverse data transfer needs.
• Multi-Trigger Modes: Hardware/software trigger, free-run, and frame sync for precise image timing.
• High Quantum Efficiency: Ensures clear imaging in low-light industrial environments.
• Industrial-Grade Reliability: IP30 protection, ESD resistance, and wide temperature range.
• Easy Configuration: Compatible with Basler Pylon SDK for parameter setup and image processing.
4. Typical Applications
• Automotive Manufacturing: Body-in-white inspection, component assembly verification, and paint defect detection.
• Electronics Production: PCB assembly inspection, semiconductor wafer defect detection, and SMT component placement control.
• Food & Beverage: Packaging integrity check, label verification, and product sorting.
• Logistics & Material Handling: Barcode reading, parcel dimensioning, and palletizing robot guidance.
• Pharmaceutical Industry: Blister pack inspection, vial filling level monitoring, and tablet sorting.
5. Installation & Maintenance
• Mounting: C-Mount/F-Mount Lens Compatibility; Panel Mount or Tripod Mount with Adapter.
• Wiring: Camera Link Cable to Frame Grabber; 12 VDC Power Supply (2.5 A Max).
• Configuration: Basler Pylon SDK for Trigger Setup, Exposure Adjustment, and Image Parameter Tuning.
• Maintenance: Periodic Lens Cleaning; Check Camera Link Connection for Signal Integrity; Update Firmware via Pylon.
• Compatibility Check: Ensure Frame Grabber Supports Camera Link Base/Medium/Full Configuration.
Technical Document | Basler A402KC (acA2040-180kc) | 4MP Industrial Camera | Machine Vision & Quality Control
