REOTRON 567LH-DP24 | Digital DC Power Controller --KIMI

Part number：REOTRON 567LH-DP24
Product Origin：America
HS CODE：8708299000
Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

REOTRON 567LH-DP24 | Digital DC Power Controller with Profibus-DP Interface

24V DC SCR Power Controller for Precise Heating, Motor Speed & Process Power Regulation in Industrial Automation

1. Product Overview

The REOTRON 567LH-DP24 is a compact digital DC power controller (thyristor-based) with Profibus-DP communication, designed to convert 3-phase 400V AC input into stable 24V DC output for industrial heating elements, DC motors, and process control actuators. Featuring phase-angle or burst-fire control, it delivers 24V DC (±1% accuracy) at 4.2A max current (100W power), with >85% efficiency and low ripple (100-200mV p-p) for precise power regulation. The module offers 2500V AC isolation between input/output/control circuits, Profibus-DP for real-time remote control, and built-in protection (overvoltage, overcurrent, overtemperature, short circuit) with fault/status relay outputs. It operates on -20°C to +60°C temperature range, ensuring reliable performance in harsh industrial environments (plastic processing, packaging, food/beverage, semiconductor manufacturing) with CE, IEC 61010-1 compliance for safety and EMC immunity.

REOTRON 567LH-DP24 (7).jpg

Key Specifications

• Model: REOTRON 567LH-DP24 (LH Series, Profibus-DP Enabled)

• Type: Digital DC Power Controller (SCR-based) with Profibus-DP Communication

• Input: 3 x 400V AC (±10%), 50/60Hz; 1-phase optional (100-240V AC)

• Output: 24V DC (±1% accuracy), 4.2A max current, 100W power, 100-200mV p-p ripple

• Control Mode: Phase-angle control or burst-fire control (user-selectable)

• Setpoint Input: 0-10V DC, 4-20mA, 10kΩ potentiometer (internal/external)

• Communication: Profibus-DP (12 Mbps max), DP V0/V1 protocol support

• Isolation: 2500V AC input-to-output, output-to-control (1 minute)

• Power Supply: 24V DC (±10%) for control circuit, 2W max

• Operating Temperature: -20°C to +60°C; Storage: -40°C to +85°C

• Protection: Overvoltage, overcurrent, overtemperature, short circuit; fault/status relays (250V AC/1A)

• Dimensions (W×H×D): 120mm × 80mm × 60mm; Weight: ~0.5kg

• Certifications: CE, IEC 61010-1, IEC 61326-1 (EMC)

REOTRON 567LH-DP24 (3).jpg

2. Core Features

• SCR-Based Power Regulation: Phase-angle/burst-fire control for precise 24V DC output (±1% accuracy).

• Profibus-DP Communication: 12 Mbps max for real-time remote setpoint adjustment and status monitoring.

• High Isolation: 2500V AC isolation prevents electrical interference and surge damage in industrial environments.

• Comprehensive Protection: Overvoltage, overcurrent, overtemperature, and short circuit protection with fault relays.

• Flexible Setpoint Input: 0-10V DC, 4-20mA, or potentiometer for easy integration with PLC/DCS.

• Low Ripple Output: 100-200mV p-p for stable operation of sensitive DC motors and heating elements.

• Wide Temperature Range: -20°C to +60°C for reliable performance in extreme industrial conditions.

• Compact Design: Space-saving for cabinet installation; DIN rail mountable.

REOTRON 567LH-DP24 (2).jpg

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement
from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea,
United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands,
Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty,
and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments
if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders.

3. Typical Applications

• Plastic Processing: Extruder barrel heating (24V DC heating elements); mold temperature control with precise power regulation.

• Packaging Machinery: Sealing bar heating (burst-fire control for consistent seal quality); DC motor speed control for conveyor systems.

• Food & Beverage: Pasteurization equipment temperature control (phase-angle control for fast response); filling machine valve actuation (24V DC solenoids).

• Semiconductor Manufacturing: Wafer processing equipment heating (low ripple for process stability); cleanroom fan speed control (4-20mA setpoint).

• Automotive: Battery testing systems (stable 24V DC power); paint curing oven temperature regulation.

REOTRON 567LH-DP24 (1).jpg

4. Installation & Maintenance

Installation: Mount on DIN rail; connect 3-phase 400V AC input (L1/L2/L3/N/PE); 24V DC output to load (twisted-pair shielded cable, max 50m). Connect Profibus-DP (A/B) and 24V DC control power. Verify insulation resistance (>100MΩ) before power-up.

Configuration: Use Profibus-DP engineering tool to set address (1-126), baud rate (9.6 kbps-12 Mbps), control mode (phase-angle/burst-fire), and setpoint range (0-10V/4-20mA).

Maintenance: Monthly: Inspect power connections; check fault/status relays. Annual: Test insulation resistance; replace module if overcurrent/overtemperature faults persist after troubleshooting.

Fault Diagnosis: Fault relay active = Check load for short circuit; DP communication loss = Verify Profibus cable/termination; Over temperature = Check ventilation and ambient temperature.

Technical Document | REOTRON 567LH-DP24 | Digital DC Power Controller with Profibus-DP for Industrial Automation
