NI SCXI-1001 4-Slot Chassis for Data Acquisition Systems
The NI SCXI-1001 is a compact 4-slot chassis from National Instruments' SCXI (Signal Conditioning eXtensions for Instrumentation) product line, designed to house and power SCXI signal conditioning modules. It serves as a foundational component for data acquisition (DAQ) systems, providing a centralized platform for signal conditioning, isolation, and routing—critical for accurate measurement of analog and digital signals in industrial, research, and test applications.
Key Technical Specifications
- Slot Configuration: 4 standard SCXI slots (compatible with all SCXI modules, including analog input/output, digital I/O, and specialty modules)
- Power Supply: AC-powered (100-240 VAC, 50/60 Hz); Provides ±15 VDC and +5 VDC to modules; Total power output: 60 W
- Backplane: SCXI bus backplane with signal routing for module communication; Supports parallel and serial module synchronization
- Dimensions (H x W x D): 177.8 mm x 228.6 mm x 304.8 mm (7 in x 9 in x 12 in); Compact benchtop or rack-mountable (with optional rack ears)
- Operating Temperature: 0°C to 55°C (32°F to 131°F); Humidity: 10% to 90% (non-condensing)
- Weight: Approximately 4.5 kg (10 lbs), lightweight for portable or benchtop setups
Compatibility: Works with NI DAQ devices (e.g., PCIe, USB, Ethernet DAQ) and LabVIEW software; Supports NI-DAQmx driver for seamless integration
Core Features
Compact & Flexible Design
4-slot configuration balances portability and expandability, ideal for small-scale test setups or space-constrained environments. Optional rack-mount ears enable integration into standard 19-inch racks for industrial or lab-wide systems.
Integrated Power Distribution
Built-in AC power supply delivers regulated voltages to all installed modules, eliminating the need for external power sources. Overload protection prevents damage to modules or the chassis during electrical anomalies.
Seamless DAQ Integration
Interfaces directly with NI DAQ devices via dedicated cables, enabling synchronized signal conditioning and data acquisition. Compatible with NI LabVIEW, LabWindows/CVI, and Measurement Studio for intuitive system configuration and data analysis.
Module Compatibility
Supports the full range of SCXI modules, including signal conditioning (amplification, filtering), isolation, multiplexing, and specialty modules for thermocouples, RTDs, or strain gauges—adapting to diverse measurement needs.
Typical Applications
Laboratory Research
Used in academic and industrial labs for signal conditioning in physics, chemistry, and engineering experiments—supporting accurate measurement of low-level or noisy signals.
Industrial Test & Measurement
Integrated into production line testing, quality control, and machine monitoring systems—conditioning signals from sensors (temperature, pressure, vibration) for reliable data acquisition.
Aerospace & Automotive Testing
Deployed in component testing (e.g., engine sensors, vehicle electronics) to condition and route signals for performance analysis and durability testing.
Educational Settings
Used in university engineering programs to teach data acquisition, signal conditioning, and system integration—providing hands-on experience with industry-standard tools.
Note: For detailed module compatibility, cabling requirements, and software configuration guidelines, refer to National Instruments' official SCXI-1001 documentation or NI Developer Zone. Ensure compatibility with newer DAQ devices and software versions by checking NI's compatibility matrix.
