GE IS200TREAH2AED Aeroderivative Turbine Emergency Trip Terminal Board (Mark VI)

Product Description

The GE IS200TREAH2AED is a dedicated emergency trip terminal board for aeroderivative gas turbines, fully integrated with the GE Mark VI Speedtronic Turbine Control System. As a core safety component, it serves as the interface between the turbine protection logic and field trip devices (e.g., overspeed sensors, pressure switches, emergency stop buttons), enabling reliable signal transmission and fail-safe trip activation. The board features a TMR (Triple Modular Redundant) voted output design with 125V DC rated contacts, voltage detection circuits (24–125V DC) for trip string monitoring, and removable barrier-type terminal blocks for organized wiring and easy maintenance. Built with surface-mount technology and industrial-grade components, it operates stably in harsh environments (-30°C to 65°C), withstands high vibration and electromagnetic interference, and complies with IEC 61010 safety standards, making it essential for aeroderivative turbine overspeed protection, emergency stop control, and safety interlock implementation.

Key Functions

The IS200TREAH2AED delivers critical safety and control capabilities for Mark VI systems: Emergency trip signal interface with TMR voted outputs (125V DC) to activate turbine trip solenoids in overspeed, overpressure, or emergency stop scenarios, ensuring failsafe protection; Voltage detection circuits (24–125V DC) for real-time monitoring of trip string integrity, enabling early fault detection and preventing false trips; Removable barrier-type terminal blocks for 24-point field wiring, simplifying installation, maintenance, and troubleshooting; Surface-mount design with high vibration resistance for reliable operation in aeroderivative turbine environments; Seamless integration with Mark VI PPRO I/O packs and protection modules for coordinated trip logic execution; Wide operating temperature range (-30°C to 65°C) and industrial-grade EMC immunity for harsh industrial conditions; Compliance with turbine safety standards (API 612, ISO 13709) for aeroderivative gas turbine applications.

Application Scenarios

The IS200TREAH2AED excels in aeroderivative turbine safety and control applications: Aeroderivative gas turbine emergency trip systems for overspeed protection, flameout detection, and lube oil pressure low trip activation in power generation and mechanical drive applications; Oil & gas for safety interlock monitoring and emergency shutdown (ESD) control of gas compressors, pipeline pumps, and offshore platform turbine generators; Power generation for grid stability protection, including generator load rejection trip and transformer fault trip integration; Industrial cogeneration for combined heat and power (CHP) systems using aeroderivative turbines, ensuring safe operation during load fluctuations; Mark VI system upgrades and retrofits to replace legacy trip terminals, enhancing safety and reducing maintenance downtime; Emergency trip system integration in mobile power units and temporary generation facilities with aeroderivative turbines.
