Honeywell LG1093AA01 is a flame detector, mainly used in Honeywell gas turbine flame monitoring systems, and is also suitable for other industrial scenarios that require the monitoring of hydrocarbon flames.

Here is its detailed introduction:

Basic information

Origin: USA.

Type: Flame detector.

Product type: LG series flame detector.

Working principle: It adopts Geiger Miller type sensor phototubes to detect ultraviolet radiation at 180-260 nanometers, which can reliably indicate whether a flame exists.

Performance characteristics

Strong anti-interference ability: It has the characteristics of resisting solar interference and withstanding blackbody radiation.

Fast response speed: The typical response time for flame presence is 0.1 seconds, and the maximum response time for flame extinction is 0.2 seconds.

Wide operating temperature range: The operating temperature range is from -40 °C to 176°C.

Output compatibility: The hardware output is compatible with the EG1033 amplifier module. For instance, EG1033AA is a transistor collector open-circuit output, while EG1033AB and EG1033AC are single-pole double-throw (SPDT) relay contact outputs.

Diverse voltage support: Supports multiple voltage requirements including 28VDC, 20-35VDC and 115VAC.

Long-distance detection: The working distance from the sensor to the amplifier can reach up to 330 meters.

Fully certified Possessing CE certification (conforming to EMC 89/336/EEC, LVD 73/23/EEC directives),

ATEX certification (Eex d Iia T3 or Eex d IIC T3, applicable to Zone 1 and Zone 2), and factory mutual recognition (applicable to Class I, Zone 1 and Zone 2, Explosive environments of Groups B, C and D.
