5SHY4045L0006/3BHB030310R0001 & 3BHE039203R0101/GVC736CE101 | IGCT Power & Gate Driver System--KIMI

Part number：5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101
Product Origin：Sweden
HS CODE：8443919090
Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ABB 5SHY4045L0006/3BHB030310R0001 & 3BHE039203R0101/GVC736CE101 | IGCT Power & Gate Driver System

High-Power Semiconductor Core for Medium-Voltage Drives, Grid & Industrial Power Conversion

1. Product Overview

The ABB 5SHY4045L0006 (order code: 3BHB030310R0001) is a 4500V/4000A integrated gate-commutated thyristor (IGCT) power module, paired with the 3BHE039203R0101/GVC736CE101 gate driver unit, forming a high-power semiconductor system for medium-voltage (MV) drives (ACS6000/ACS800MV), HVDC, and FACTS applications. The IGCT module combines thyristor high-voltage current handling with IGBT-like fast switching, achieving low-conduction loss (<3.5V typical) and sub-10μs turn-off for efficient power conversion. The GVC736CE101 gate driver delivers precise gate signals, real-time monitoring (temperature/current/voltage), and fast fault protection (overcurrent/overtemperature/short-circuit) with fiber-optic isolation for EMC immunity. With dual-side cooling, IP20 protection, and -40°C to +125°C junction temperature range, this system ensures 24/7 reliability in harsh industrial environments, compliant with IEC 61800-5-1 and UL 60950-1 safety standards.

ABB 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 (2).png

Product ID:3BHB030310R0001

ABB model name :4500V, 91mm, 5SHY 4045L0006

Catalogue Description :4500V, 91mm, 5SHY 4045L0006; IGCT MODULE

Detailed description :4500V, 91mm, 5SHY 4045L0006

Change product ID (OLD) :

3BHB020720R0002

3BHL000986P3105

3BHB013085R0001

Key Specifications (IGCT Power Module: 5SHY4045L0006/3BHB030310R0001)

• Model: 5SHY4045L0006 (Order Code: 3BHB030310R0001)

• Technology: Integrated Gate-Commutated Thyristor (IGCT)

• Voltage Rating: 4500V (VDRM/VRRM), 4000A (ITAV, 180° conduction, dual-side cooling)

• Surge Current: 70kA (10ms), Gate Trigger: ≤3.0V/≤300mA

• Switching Performance: Max di/dt ≥1000A/μs, Max dv/dt ≥1000V/μs, fsw up to 1600Hz

• Thermal Resistance: Junction-to-Case (RthJC)<0.01°C/W (dual-side cooling)

• Cooling: Forced water cooling or dual-side heatsink compression

• Protection: Overcurrent, Overtemperature, Short-Circuit (via GVC736CE101 driver)

• Dimensions: ~300×200×100mm, Weight: ~3kg

ABB 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 (8).png

Key Specifications (Gate Driver Unit: 3BHE039203R0101/GVC736CE101)

• Model: GVC736CE101 (Order Code: 3BHE039203R0101)

• Function: Precision gate driving, real-time monitoring, fast fault protection for IGCT modules

• Isolation: Fiber-optic communication (EMC immunity), Safety Interlock (IEC 61800-5-1 compliant)

• Monitoring: Temperature, Current, Voltage, Gate Status, Fault Diagnosis

• Protection: Overcurrent (I²t), Overtemperature, Short-Circuit, Undervoltage Lockout (UVLO)

• Power Supply: 24VDC (±10%), Max Power Consumption: 50W

• Communication: Fiber-optic to control system (e.g., PMI board in ACS6000)

• Dimensions: ~200×150×60mm, Weight: ~0.8kg, Mounting: DIN rail or panel

ABB 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 (10).png

2. Core Features

• High-Power Density: 4500V/4000A IGCT module for medium-voltage (6kV/11kV) drive systems.

• Low-Loss Switching: IGCT combines thyristor low conduction loss with fast turn-off for energy-efficient conversion.

• Precision Gate Control: GVC736CE101 provides accurate gate timing, ensuring stable switching and minimal EMI.

• Real-Time Monitoring: Driver unit tracks temperature, current, voltage, and gate status for predictive maintenance.

• Fast Fault Protection: Sub-μs response to overcurrent/short-circuit; fiber-optic isolation prevents system damage.

• Dual-Side Cooling: Optimized thermal design for high-power dissipation in harsh industrial environments.

• System Integration: Compatible with ABB ACS6000/ACS800MV MV drives; works with PMI control boards.

• Global Compliance: IEC 61800-5-1, UL 60950-1, CE certifications for safety and EMC.

ABB 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 (6).png

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement
from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan, South Korea,
United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands,
Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty,
and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments
if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders.

3. Typical Applications

• Medium-Voltage Drives: ABB ACS6000/ACS800MV for large motors in mining, cement, and petrochemical industries.

• Power Transmission: HVDC converter stations and FACTS (SVC/STATCOM) for grid stability.

• Renewable Energy: Wind turbine converters and solar inverter systems for grid integration.

• Industrial Processing: High-power induction heating, rolling mill drives, and marine propulsion systems.

• Railway Traction: Medium-voltage traction converters for electric locomotives and high-speed trains.

ABB 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101 (5).png

4. Installation & Maintenance

Installation: Mount IGCT module on dual-side heatsink; connect water cooling lines (flow rate ≥5L/min). Wire GVC736CE101 to IGCT gate terminals; fiber-optic link to PMI control board. Verify insulation resistance (>100MΩ) before power-up.

Configuration: Use ABB Control Builder M to set gate driver parameters (trigger voltage/current, fault thresholds). Calibrate temperature/current sensors for accurate monitoring.

Maintenance: Monthly: Check cooling system pressure/flow; inspect gate connections. Annual: Test thermal resistance; replace gate driver if fault codes persist. Replace IGCT after 10^6 switching cycles or surge current events.

Fault Diagnosis: Driver fault LED = Check overcurrent/overtemperature; Fiber link error = Inspect fiber-optic cables; IGCT failure = Verify insulation and gate resistance.

Recommended products and services

You can click on (ABB ) to visit the official website for more product information.

If you want to purchase, you can contact YMGK's official customer service

For the relevant manual, please click to download and learn about the specific parameters

5SHY4045L0006 3BHB030310R0001.pdf
