Brief Product Description

The IS200TBCIH2BBD is a 24‑channel dry‑contact termination board for GE Mark VIe turbine control systems. Designed to interface field‑discrete switch signals to PDIA I/O packs, this conformal‑coated circuit board provides group‑isolated contact‑input wiring terminals, hardware signal filtering and surge protection. Built for long‑term continuous operation in power‑plant environments, it supports simplex, duplex and triple‑modular‑redundant (TMR) safety‑control configurations for gas and steam‑turbine protection racks.

Core Product Functions

• 24 independent dry‑contact input channels connected via two barrier‑style terminal blocks
• 4‑millisecond hardware input filtering to suppress transient noise and signal‑bounce interference
• Electrical group‑to‑group isolation prevents fault propagation across different signal loops
• Transmit discrete field status signals to Mark VIe PDIA digital‑input I/O modules
• Built‑in surge‑voltage suppression circuits for harsh electromagnetic industrial environments
• Conformal PCB coating provides protection against dust, humidity and corrosive airborne contaminants
• Compatible with simplex, dual‑redundant and TMR turbine safety‑control architectures
• Front‑mounted LED indicators for quick visual status and fault diagnostics
• ‑30°C ~ +65°C wide operating‑temperature range for cabinet installation

Application Scenarios

• Gas‑turbine and steam‑turbine Mark VIe safety interlock control racks in power‑generation plants
• Generator circuit‑breaker, valve‑position and auxiliary‑equipment status signal monitoring
• Combined‑cycle power‑plant distributed turbine control and protection cabinets
• Off‑shore and on‑shore oil‑gas rotating‑machinery safety‑control systems
• Industrial cogeneration and refinery turbine auxiliary‑control signal acquisition panels
• Spare replacement termination board for maintenance and upgrade of legacy Mark VIe installations

FAQ (Frequently Asked Questions)

• Q: No contact‑input status changes are detected by the Mark VIe controller?
  A: Inspect loose terminal wiring, damaged ribbon‑cable connection to PDIA pack, failed field dry‑contact switch, or board hardware failure.
• Q: Random false contact‑input signals appear during stable turbine‑operation?
  A: Check for poor cable shielding, inadequate grounding, high‑voltage EMI interference or degraded wiring insulation.
• Q: Can IS200TBCIH2BBD be hot‑swapped while the control rack remains powered‑on?
  A: Hot‑swap is not recommended. Disable relevant safety interlock loops before replacing the board to avoid accidental turbine trips.
• Q: Will this board work with other third‑party control systems?
  A: It is a dedicated Mark VIe termination board and designed exclusively for matching GE PDIA I/O packs; cross‑system compatibility is not supported.
• Q: Is this board still available for new‑build turbine‑control projects?
  A: This legacy Mark VIe‑series board has reached end‑of‑life. Only surplus, rebuilt and refurbished spare‑part units are offered for existing‑site maintenance.
