PM858K02  3BSE082896R1 Redundant Processor Unit

PM858K02 3BSE082896R1 is a redundant processor unit specially designed by ABB for the 800xA control system.

It is equipped with dual Intel® Xeon® E5-2690 v2 2.3GHz processors, has 32GB DDR3 memory and 2 pieces of 250GB SSD storage, and runs Windows Server 2012 R2 operating system.

Equipped with 2 Gigabit Ethernet ports and 1 RS-232 port, it ensures continuous operation through redundant components and is suitable for industrial fields with extremely high reliability requirements such as power, oil and gas, and transportation.

The CPU board contains the microprocessor and RAM memory, a real-time clock, LED indicators, INIT push button, and a CompactFlash interface.
The base plate of the PM858 controller has two RJ45 Ethernet ports (CN1, CN2) for connection to the Control Network, and two RJ45 serial ports (COM3, COM4). One of the serial ports (COM3) is an RS-232C port with modem control signals, whereas the other port (COM4) is isolated and used for the connection of a configuration tool. The controller supports CPU redundancy for higher availability (CPU, CEX-Bus, communication interfaces and S800 I/O).

Simple DIN rail attachment / detachment procedures, using the unique slide & lock mechanism. All base plates are provided with a unique Ethernet address which provides every CPU with a hardware identity. The address can be found on the Ethernet address label attached to the TP830 base plate.

(Only compatible with System 800xA 6.0.2, Compact Control Builder 6.0.0-1 and onwards. Please see product Update for more information.)

Product net depth: 135 millimeters

Product clear height: 186 millimeters

Product net width :119 millimeters

Net weight of the product: 2.7 kilograms

Product Number: 3BSE082896R1

ABB model name: PM858K02

Directory Description: PM858K02 Redundant Processor Unit

Package including:
2 pcs PM858, CPU
2 pcs TP830, Baseplate
2 pcs TB807, ModuleBus terminator
1 pcs TK850, CEX-bus expansion cable
1 pcs TK851, RCU-Link cable
2 pcs Battery for memory backup (4943013-6) one for each controller

Features and benefits

•  ISA Secure certified - Read more

•  Reliability and simple fault diagnosis procedures

•  Modularity, allowing for step-by-step expansion

•  IP20 Class protection without the requirement for enclosures

•  The controller can be configured with 800xA control builder

•  The controller has full EMC certification

•  Sectioned CEX-Bus using a pair of BC810 / BC820

•  Hardware based on standards for optimum communication connectivity

    (Ethernet, PROFIBUS DP, etc.)

•  Built-in redundant Ethernet Communication ports
