ABB REF542PLUS digital protective relay

Time：2025-05-29 16:17:53 View count：

Product Number:ABB REF542PLUS digital protective relay

Product Overview

ABB REF542PLUS is a digital protective relay belonging to ABB's REF542 series. The following is its relevant information:

Functional features:

High precision and high reliability: With advanced hardware and software design, it can ensure the long-term stable operation of the equipment.

Multi-functional integration: It integrates measurement, monitoring, protection, control and self-diagnosis functions, enhancing the reliability and efficiency of the system.

Flexibility and scalability: Supports multiple communication protocols such as Modbus, IEC 61850, and DNP3.0, and can adapt to different application scenarios.

User-friendly: It features an intuitive graphical human-machine interface (HMI), supports Chinese display, and simplifies configuration and operation.

Technical parameters:

Voltage range: Typically designed for systems ranging from 6 to 36kV, specific parameters can be customized according to application requirements.

Current range: Up to 6000A at most.

Communication interface: Supports multiple communication protocols, facilitating integration with the upper computer system.

Operating temperature: -25℃ to + 70℃ or -40 ℃ to + 85℃, protection grade is IP20 or IP65.

Dimensions and weight: The external dimensions are 225mm x 110mm x 50mm, and the weight is 2.0kg.

Protection functions: It provides comprehensive electrical protection functions, including overcurrent, ground fault, undervoltage, overvoltage, short circuit, thermal overload and other protections.

Measurement function: Precisely measure electrical parameters such as voltage, current, power, and power factor.

Control function: Achieve remote control of feeder equipment, such as switch operation, ratio adjustment, etc.

Monitoring function: Real-time monitoring of the equipment's operating status and providing rich alarm information.

Self-diagnostic function: Regularly conduct self-checks on the equipment and provide fault diagnosis information.

Application field:

Distribution automation: As an important component of the distribution automation system, it realizes the remote monitoring and control of the distribution network.

Industrial automation: Protecting the power distribution systems of industrial enterprises to ensure the safe operation of critical loads.

New energy access: Applicable to the access of new energy sources such as photovoltaic power generation and wind power generation to distribution networks.

Motor protection: It is used for the protection of induction motors, synchronous motors, as well as pumps, fans, conveyors, compressors and other motors.

ABB REF542PLUS digital protective relay
