R. STAHL 9475/32-08-52 IS1+ Digital Input Module

Product Description

The 9475/32-08-52 is an 8-channel intrinsically safe digital input module belonging to the R. STAHL IS1+ remote I/O system, certified for Zone 1 hazardous locations. It is designed to collect dry contact, Namur and 24V DC binary signals from field explosion-proof sensors and switches. Each channel provides independent intrinsic safety protection, open-circuit and short-circuit diagnosis, and supports hot-swap operation while energized. It communicates with the IS1+ CPM controller via the internal BusRail backplane bus.

Features

• 8 Ex ia IIC intrinsically safe digital input channels
• Supports Namur sensors, dry contact switches and 24V binary field signals
• Individual channel diagnostics for wire breakage and short circuit
• Hot-swap replacement in Zone 1 hazardous area without power shutdown
• Galvanic isolation between field side and backplane bus
• LED status indicators for each channel and module power status
• Compact DIN rail mounted module for IS1+ BusRail rack
• Explosion protection certificate Ex ia IIC T4, operating temperature -20℃ ~ +60℃

Application Scenarios

• Oil, gas and chemical Zone 1 hazardous area digital signal acquisition
• Namur proximity switch, limit switch and valve feedback signal collection
• Flame detectors, flow switches and pressure switch binary signal monitoring
• Offshore platform and refinery explosion-proof remote I/O cabinet construction
• IS1+ system spare parts replacement and automation upgrade projects

FAQ

Q: What type of signals does this module receive?
A: Namur signals, dry contact and 24V DC digital input signals.

Q: Can it be hot swapped?
A: Yes, it supports hot swap in Zone 1 hazardous locations.

Q: Which system does it belong to?
A: It is part of the R. STAHL IS1+ intrinsically safe remote I/O system.

Q: How many channels are available?
A: 8 independent digital input channels with intrinsic safety protection.
