Siemens 6GK1162-8AA00 SIMATIC NET CP 1628 Communications Processor

Product Description

The 6GK1162-8AA00 is Siemens CP 1628 PCI Express X1 communication card for Industrial Ethernet / PROFINET. It comes with an integrated 2-port RJ45 switch and supports 10/100/1000 Mbps gigabit Ethernet. It has built-in security functions including firewall and VPN, works with HARDNET-IE S7 and S7-REDCONNECT for high-availability redundant S7 communication. It is installed in industrial PCs to connect with Siemens PLCs, SCADA and PROFINET field devices.

Features

• PCIe X1 interface, 3.3V /12V power supply for IPC slot
• Dual RJ45 gigabit ports with integrated switch, supports linear and ring topology
• 10/100/1000 Mbps auto-negotiation, compatible with PROFINET and Industrial Ethernet
• Onboard firewall and VPN security engine for secure industrial remote access
• Supports S7-REDCONNECT for redundant PLC communication links
• Hardnet real-time communication for high-speed S7 data exchange
• Works with SIMATIC NET software for configuration and diagnostics
• Optional external 24V DC power supply for stable operation

Application Scenarios

• Industrial PC (IPC) communication with S7-300/400/1200/1500 PLCs
• PROFINET real-time control and factory automation systems
• Redundant control network with S7-REDCONNECT high availability
• SCADA server and HMI station secure industrial network connection
• Remote maintenance and VPN access for factory automation equipment

FAQ

Q: What is the model name?
A: CP 1628, SIMATIC NET communication processor card.

Q: What interface does it use?
A: PCI Express X1, designed for industrial PC installation.

Q: Does it support redundant communication?
A: Yes, it supports S7-REDCONNECT for redundant S7 communication channels.

Q: What security functions are integrated?
A: Built-in firewall and VPN for secure industrial communication.
