ABB PPD113B03-26-100110 | 3BHE023584R2634
Symphony Plus Excitation Control Module for Generator & Turbine Synchronization
1. Product Overview
The ABB PPD113B03-26-100110 (3BHE023584R2634) is a high-performance excitation control module belonging to the ABB Symphony Plus industrial control system family, engineered for precise excitation regulation, generator voltage control, and turbine synchronization in power generation, marine, and industrial power systems. As a key component of ABB's excitation control system (ECS), it integrates advanced PID control algorithms, real-time data acquisition, and multi-protocol communication, supporting both brushless and static excitation systems for synchronous generators (0.5MW to 1000MW+). The module features high-speed analog/digital signal processing, comprehensive fault detection, and seamless integration with ABB Symphony Plus DCS, Relion protection relays, and third-party SCADA systems. With a rugged industrial design, -40°C to +70°C operating range, and SIL 2 compliance (IEC 61508), it delivers reliable, high-precision excitation control for grid-connected and isolated generator operation, ensuring voltage stability, reactive power optimization, and fast fault response in 24/7 critical power applications.
Key Specifications
• Model: PPD113B03-26-100110 | Order Code: 3BHE023584R2634 | Series: ABB Symphony Plus
• Type: Excitation Control Module (ECM) for Synchronous Generator Systems
• Control Capability: 0.5MW to 1000MW+ synchronous generators; brushless/static excitation systems
• Inputs: 8x Analog (4-20mA/0-10V); 16x Digital (24V DC); 2x Speed/Pulse Inputs (0-10kHz)
• Outputs: 4x Analog (4-20mA/0-10V); 8x Digital (24V DC/Relay); PWM excitation signal output
• Control Algorithms: Advanced PID; AVR (Automatic Voltage Regulator); Reactive Power Control; Synchronization
• Communication: Modbus RTU/TCP; Profibus DP; ABB SPA Bus; Ethernet IP (10/100 Mbps)
• Power Supply: Dual redundant 24V DC (18-32V DC); Power Consumption<15W
• Environmental: Operating -40°C to +70°C; Storage -40°C to +85°C; Humidity 5-95% (non-condensing)
• Certifications: IEC 61508 (SIL 2), IEC 61800-5-1, CE, RoHS, UL 508
2. Core Features
• High-Precision AVR Control: ±0.2% voltage regulation accuracy for grid-connected/isolation generator operation, ensuring stable output
• Dual Redundancy Design: Redundant power supply + communication ports for zero-downtime operation in critical power systems
• Multi-Mode Excitation Control: Supports voltage, reactive power, power factor, and cross-current compensation control modes
• Fast Synchronization: Automatic generator synchronization (speed/phase/voltage matching) with<100ms response time
• Comprehensive Fault Protection: Overvoltage/undervoltage, overcurrent, overfrequency/underfrequency, and field loss protection with fast trip
• Seamless System Integration: Plug-and-play with ABB Symphony Plus DCS, Relion protection relays, and third-party SCADA/PLC
• Real-Time Diagnostics: Built-in self-test (BIST), event logging (100,000+ events), and LED status indicators for remote troubleshooting
• Rugged Industrial Design: Vibration/shock resistance (IEC 60068-2); conformal coating option for harsh dust/humidity environments
