ABB FS300R17KE3 / AGDR-76C IGBT Module + Gate Driver Board Assembly

Product Description

The FS300R17KE3 is an Infineon IGBT power module paired with ABB AGDR-76C gate driver board, widely used for ABB high-power ACS800 series inverter units. FS300R17KE3 is a 1700V, 300A IGBT module responsible for power switching; AGDR-76C is the dedicated drive board which provides isolated driving signals, short-circuit protection and fault feedback for the IGBT module. This combined assembly is a core spare part for high-power variable frequency drive maintenance.

Features

• FS300R17KE3: 1700V, 300A IGBT power module
• AGDR-76C dedicated matching gate driver board for ABB ACS800 drives
• Integrated overcurrent, short-circuit and desaturation protection functions
• Isolated drive signal transmission, strong anti-interference ability
• High switching performance, suitable for heavy-load variable frequency occasions
• Complete assembly for direct replacement of faulty units in inverter power sections
• Supports real-time fault signal feedback to the main control board

Application Scenarios

• ABB ACS800 high-power inverter power unit maintenance
• Metallurgy, mining, chemical industry high-power fan and pump drive
• Conveyor, hoist and heavy machinery variable frequency control cabinet
• Power plant auxiliary equipment frequency conversion transformation
• Industrial high-power variable frequency drive spare parts stock

FAQ

Q: Which inverter series is this assembly suitable for?
A: Mainly for ABB ACS800 series high power inverters.

Q: What is the rating of FS300R17KE3?
A: 1700V voltage rating, 300A continuous current.

Q: Can AGDR-76C drive other IGBT modules?
A: It is specially matched with FS300R17KE3, not recommended for other unmatched IGBTs.

Q: What common faults are related to this set?
A: Inverter output short circuit, IGBT breakdown, drive fault alarm, no output.
