Allen-Bradley 80190-300-01-R Extended I/O Board for PowerFlex 7000

Product Description

The Allen-Bradley 80190-300-01-R is an extended I/O circuit board dedicated to Rockwell PowerFlex 7000 medium voltage drives. It provides additional digital and analog signal interfaces for the drive control system, supporting field signal collection, interlock logic and remote control commands. Powered by 24VDC, it is equipped with status indicator LEDs for quick signal diagnosis. It serves as a critical field signal expansion spare part for legacy PowerFlex 7000 MV variable frequency systems.

Product Functions

• Collect digital interlock, run feedback, fault reset and ready status signals from field devices
• Output relay and digital control signals for external contactors, alarms and interlock loops
• Process analog signals for auxiliary temperature, pressure and flow monitoring
• Transfer I/O status data between the main drive controller and on-site field instruments
• Onboard LED indicators to visualize channel status for convenient troubleshooting
• Chassis plug-in design, directly compatible with the original PowerFlex 7000 control cabinet rack

Application Scenarios

• Power plant large fans, blowers and circulating pump medium voltage drive control systems
• Oil & gas, mining compressors and heavy pump interlock and monitoring cabinets
• Cement, metallurgy and chemical medium voltage variable frequency drive equipment
• Water treatment and utility large motor energy-saving MV drive systems
• Spare replacement, repair and retrofit of existing PowerFlex 7000 drive units
