Allen‑Bradley 2364‑SPM03A System Performance Monitor Module for Power Systems
Product Description
The Allen‑Bradley 2364‑SPM03A is a high-precision System Performance Monitor (SPM) module from Rockwell Automation, designed to provide real-time monitoring, analysis, and reporting of electrical power system performance in industrial, commercial, and utility applications. This compact, DIN-rail mountable module integrates 3-phase voltage/current measurement, power quality analysis (harmonics, flicker, transients), and energy metering—while supporting Modbus TCP/IP and Ethernet/IP communication for seamless integration with Allen‑Bradley PLCs, HMIs, and enterprise energy management systems. Engineered for compliance with IEEE 1159 and IEC 61000 power quality standards, it delivers actionable insights to optimize energy usage, reduce downtime, and ensure regulatory compliance.
Key Functions
The 2364‑SPM03A delivers comprehensive power system monitoring and analysis with these core capabilities: 3-phase voltage/current/power measurement (V, I, kW, kVAR, kVA, PF, frequency) with 0.2% accuracy class; power quality analysis (total harmonic distortion (THD) up to 50th harmonic, voltage flicker, voltage sags/swells, transients, unbalance); energy metering (kWh, kVARh, kVAh) with interval data logging (1-minute to 1-hour intervals); configurable alarm thresholds (overvoltage/undervoltage, overcurrent, high THD) with digital output signaling; dual communication interfaces (Modbus TCP/IP, Ethernet/IP) for integration with Rockwell Automation ControlLogix/CompactLogix PLCs and SCADA systems; built-in web server for remote configuration, monitoring, and report generation (PDF/CSV export); and compliance reporting for IEEE 1159/IEC 61000 standards.
Application Scenarios
The 2364‑SPM03A is deployed in industrial, commercial, and utility power systems requiring detailed performance and power quality monitoring. In manufacturing plants, it monitors motor control centers, variable frequency drives (VFDs), and production line power to identify harmonic issues and optimize energy usage. For data centers and critical infrastructure (hospitals, airports), it ensures power quality compliance and detects voltage sags/swells that could disrupt sensitive equipment. In commercial buildings (office towers, retail centers), it tracks energy consumption across multiple circuits for cost allocation and sustainability reporting. The module is also ideal for utility distribution systems, where it monitors feeder power quality and supports regulatory compliance reporting.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | System Performance Monitor (SPM) Module |
| Manufacturer | Allen‑Bradley (Rockwell Automation) |
| Model/Part Number | 2364‑SPM03A |
| Measurement Inputs | 3-Phase Voltage: 120/208/240/480 VAC L-L (configurable); 3-Phase Current: 0-5 A AC (CT input, 5 A nominal) |
| Accuracy Class | 0.2% for Voltage/Current/Power; 0.5% for Energy Measurement |
| Power Quality Analysis | THD (Voltage/Current up to 50th Harmonic); Voltage Sags/Swells; Transients; Voltage Flicker; Phase Unbalance |
| Communication Interfaces | Ethernet/IP, Modbus TCP/IP (10/100 Mbps RJ45); Built-in Web Server (HTTP/HTTPS) |
| Power Supply | 85-265 VAC (50/60 Hz) or 100-300 VDC; Power Consumption: 10 W max |
| Data Logging | Interval Logging: 1-Minute to 1-Hour; Storage: Up to 1 Year of Historical Data (internal flash) |
| Outputs/Alarms | 4 Digital Outputs (Form C, 5 A @ 250 VAC/30 VDC); Configurable Alarm Thresholds (16 User-Defined Alarms) |
| Operating Environment | Temperature: -20°C to +60°C (-4°F to +140°F); Humidity: 5-95% RH (Non-Condensing); IP20 Protection Rating |
| Mechanical Features | DIN Rail Mountable (35 mm); Dimensions: 120 x 100 x 75 mm (WxHxD); Weight: 0.8 kg (1.76 lb) |
| Compliance & Certifications | IEEE 1159, IEC 61000-4, CE, UL, CSA, RoHS Compliant |
