5069-L320ER Allen‑Bradley CompactLogix 5380 Controller

Product Description
5069-L320ER is a CompactLogix 5380 PLC controller manufactured by Rockwell Automation Allen‑Bradley. It features 2MB user memory, dual integrated Ethernet/IP ports, supports up to 16 local I/O modules and 40 EtherNet/IP nodes. It is a mid-range compact controller designed for discrete, hybrid and simple motion control applications, delivering high performance with small footprint for factory automation systems.

Key Features

• 2 MB application memory, dual-channel EtherNet/IP for device-level ring (DLR) network redundancy
• Support up to 16 local 5069 series I/O modules, maximum 40 EtherNet/IP connected devices
• Built-in SD card slot for program backup, firmware update and data logging
• High-speed task execution, compatible with Studio5000 Logix Designer software
• Compact rail mounting, low power consumption, wide industrial operating temperature range
• Non-safety standard controller, no safety-rated function

Application Scenarios

• Packaging machinery, material handling, conveyor systems
• Automotive assembly auxiliary lines, metal processing equipment
• Food & beverage production, water treatment and general factory automation
• Small to medium sized machine control with EtherNet/IP distributed I/O

FAQ

Q: What software is required for programming 5069-L320ER?
A: Studio5000 Logix Designer, minimum firmware version matching the controller revision.

Q: Does 5069-L320ER support motion control?
A: It can perform basic motion over EtherNet/IP; for advanced multi-axis motion, select 5069-L320ERM motion version.

Q: Is this a safety PLC?
A: No. Safety version is Compact GuardLogix 5380 series like 5069-L320ERMS3 with SIL3 rating.
