Meggitt Vibro-Meter CMC16 200-530-025-016 Condition Monitoring Card

Product Description

200-530-025-014 CMC-16 is a high-performance condition monitoring card for the Meggitt Vibro-Meter VM600 machinery protection system. It is a 6U VME plug-in board equipped with on-board DSP for real-time vibration signal acquisition and analysis. The module has 16 dynamic signal channels for vibration and dynamic pressure measurement plus 4 tachometer speed inputs, 24-bit high precision sampling, supports synchronous / asynchronous sampling and high resolution FFT spectrum analysis. Powered by rack 18~36VDC, it complies with IEC61508 SIL2 and API670 standards, uses IOC4 bus to communicate with VM600 rack controller, paired with VibroSight software for configuration, data viewing and post-fault analysis. This product has been discontinued, market available stock are new surplus or tested refurbished spares for turbine and compressor monitoring rack replacement.

Key Functions

• 16-channel dynamic vibration signal acquisition + 4 tachometer speed input for rotating machinery
• Onboard DSP real-time FFT spectrum analysis, waveform capture and trend calculation
• High precision 24-bit ADC, anti-aliasing filter and galvanic signal isolation
• Continuous monitoring of vibration amplitude, frequency spectrum, phase and fault characteristic values
• Supports threshold alarm output, event logging and raw waveform storage for failure analysis
• IOC4 bus internal rack communication, Ethernet data upload via VM600 CPU-M module
• Self-diagnosis for sensor open/short circuit, module hardware fault and power supervision
• Meets SIL2 safety requirement, anti-vibration design suitable for power and oil & gas field cabinets

Application Scenarios

• Gas turbine, steam turbine and generator vibration condition monitoring
• Oil & gas centrifugal compressor, pump and fan machinery monitoring rack
• Power plant turbomachinery protection and predictive maintenance system
• Offshore platform rotating equipment health monitoring
• Retrofit and spare replacement for existing VM600 monitoring systems

FAQ

Q1: What does CMC16 stand for?
A1: CMC = Condition Monitoring Card, 16 represents 16 dynamic measurement channels.

Q2: What software configures this module?
A2: VibroSight software for parameter setup, waveform viewing and vibration trend analysis.

Q3: What is the safety level?
A3: IEC61508 SIL2, conforming to API 670 machinery monitoring standard.

Q4: Common failure symptoms?
A4: Partial channel no vibration reading, spectrum data loss, communication failure with CPU-M, DSP hardware fault alarm.
