VAMP V57F4-AAA2BBA Feeder Protection IED

Product Description

V57F4-AAA2BBA belongs to VAMP 57 series arc flash and feeder protection relay, developed by VAMP (now part of Schneider Electric). It is a multifunctional intelligent electronic device for medium voltage switchgear protection, monitoring and control. The ordering code defines: wide auxiliary power 48–230V AC/DC, 24V digital input nominal voltage, 4 current and 4 voltage measurement inputs, 16 digital inputs and 8 digital outputs plus 1 signal fail relay, equipped with RS485 communication interface. This relay integrates arc flash protection, overcurrent, earth fault, voltage protection and disturbance recording. 19-inch panel mounting, with high-speed arc detection capability, conformal coated PCB option, strong EMC performance for harsh substation environment.

Key Functions

• Ultra-fast arc flash protection to minimize arc fault damage in MV switchgear
• Full set feeder protection: phase overcurrent, earth fault, overvoltage, undervoltage, negative sequence protection
• 4 current and 4 voltage analog measurement, power metering and energy calculation
• 16 DI / 8 DO + 1 SF relay for breaker control, status acquisition and alarm output
• Built-in fault recorder, event log, disturbance waveform capture for post-fault analysis
• RS485 communication port, support Modbus RTU protocol for SCADA connection
• Self-monitoring, watchdog and hardware fault alarm, panel LED status indication

Application Scenarios

• Medium voltage switchgear feeder protection and arc flash mitigation
• Industrial plant, mining and oil & gas power distribution substations
• Wind farm, solar power station medium voltage cabinet protection
• Building power center and utility distribution network protection
• Retrofit upgrade for existing MV switchgear arc protection systems

FAQ

Q1: What is the power supply range?
A1: 48~230V AC/DC wide range auxiliary power.

Q2: What communication interface does this model have?
A2: RS485 with Modbus RTU protocol.

Q3: What is the core advantage of VAMP57?
A3: Extremely fast arc flash detection and tripping, greatly reduces arc explosion hazard in switchgear.

Q4: Common faults?
A4: Loss of communication, DI/DO channel failure, incorrect current/voltage reading, arc sensor circuit fault.
